Side 1/2

2. Install Hand Shower

In2ition

Installation Instructions

Parts Included

Shower Head

Hand Shower

3. Insert Hand Shower into Shower Head

a. Slide Hand Shower

into the top of the

Shower Head.

b. Gently push the

Hand Shower

down into the

Shower Head.

• If the Shower

Head moves when

inserting or

removing the

Hand Shower,

hand tighten the

connection

between the

Shower Head and

the Ball Connector.

Place the hose washers into the hose nuts on each end

of the hose.

Attach the end of the hose with a hex nut to the

shower head. Connect the other end of the Metal Hose

to the Hand Shower. All connections should be able to

be made by hand tightening only.

To change spray modes, turn the lever (located on the

front of the Hand Shower) left or right to the desired

setting.

Metal Hose

1. Install the Shower Head

4. Removing the Hand Shower from the Shower Head

Push the lower part

of the Hand Shower

upwards, away from

the Shower Head.

Pull the Hand

Shower away from

the slot in the

Shower Head.

Hose Washer

(2)

Turn off water supply before installing the Shower Head.

Remove existing Shower Head from Shower Arm.

Apply plumber tape (not included) to Shower Arm, if necessary,

to stop or prevent leaks.

Hand tighten the Ball Connector of the Shower Head to the

Shower Arm.

2a. Changing Modes From Shower Head, to Hand Shower, or to Both

Turn knob on side of Shower Head to change between:

• Shower Head only

• Shower Head and Hand Shower

• Hand Shower only

6467 Rev. C07/03/2020

Control

Knob

Hex Nut

Ball Connector

WARNING:

Notice: Removal of or tampering with the flow restrictor may result in showerhead failure and will void the warranty.

Backflow Protection

If your product is not equipped with backflow prevention, in order to make your product backflow compliant, a vacuum breaker will need to be added.

Plumbing Codes require that shower heads and hand showers provide a small but continuous ﬂow of water (trickle) when in “PAUSE” mode. Because of this continuous ﬂow, in certain circumstances

pressure variations in the water line and/or changes in the position of shower temperature control handle while in “PAUSE” mode could result in dramatic changes to the temperature of the water when the shower

head or hand shower is returned to the “ON” position.

ALWAYS point the shower head away from yourself when returning to the “ON” position and feel the water with your hand before resuming your shower to ensure the water ﬂow is not too hot or too cold. DO NOT

allow children or others who might not understand this warning to use the “PAUSE” function.

6467 Rev. C07/03/2020

Parts and Finish. All parts (other than electronic parts and batteries) and finishes of Delta

faucets purchased from authorized Delta sellers

are warranted to the original consumer purchaser to be free from defects in material and workmanship for as long as the original consumer

purchaser owns the home in which the faucet was first installed. For commercial purchasers, (a) the warranty period is ten (10) years for

multi-family residential applications and (b) five (5) years for all other commercial applications, in each case from the date of original purchase.

For purposes of this warranty, the term “multi-family residential application” refers to the purchase of the faucet from an authorized Delta seller

by a purchaser who owns but does not live in the residential dwelling in which the faucet is initially installed, such as in a rented or leased

single unit or multi-unit detached home (duplex or townhome), or a condominium, apartment building or community living center. The following

installations are not considered multi-family residential applications, are excluded from the 10-year warranty and are subject to the 5-year

warranty: industrial, institutional or other business premises, such as a dormitory, hospitality premises (hotel, motel or extended stay location),

airport, educational facility, long- or

short-term healthcare facility (hospital, rehabilitation center, nursing, assisted or staged-care living unit),

public space or common area.

Parts and Finish for Delta

Recertified Faucets. Delta Faucet Company offers for sale on deltafaucet.com Delta

Recertified faucets. All

parts (other than electronic parts and batteries) and finishes of these Delta

Recertified faucets are warranted to the original consumer pur-

chaser to be free from defects in material and workmanship for ten (10) years from the date of original purchase. For commercial purchasers,

the warranty period is one (1) year from the date of original purchase.

Electronic Parts. Electronic parts (other than batteries), if any, of Delta

faucets purchased from deltafaucet.com or authorized Delta sellers

are warranted to the original consumer purchaser to be free from defects in material and workmanship for five (5) years from the date of

original purchase or, for commercial purchasers, for one (1) year from the date of original purchase. No warranty is provided on batteries.

What We Will Do. Delta Faucet Company will repair or replace, free of charge, during the applicable warranty period (as described above),

any part or finish that proves defective in material and/or workmanship under normal installation, use and service. If

repair or replacement

is not practical, Delta Faucet Company may elect to refund the purchase price in exchange for the return of the product. These are your

exclusive remedies.

What Is Not Covered. Because Delta Faucet Company is unable to control the quality of Delta products sold by unauthorized sellers, unless

otherwise prohibited by law, this warranty does not cover Delta products purchased from unauthorized sellers.

Any labor charges incurred by the purchaser to repair, replace, install or remove this product are not covered by this warranty. Delta Faucet

Company shall not be liable for any damage to the faucet resulting from reasonable wear and tear, outdoor use, misuse (including use of the

product for an unintended application), freezing water, abuse, neglect or improper or incorrectly performed installation, maintenance or repair,

including failure to follow the applicable care and cleaning instructions. Delta Faucet Company recommends using a professional plumber for

all installation and repair of faucets. We also recommend that you use only genuine Delta

replacement parts.

What You Must Do To Obtain Warranty Service or Replacement Parts. A warranty claim may be made and replacement parts may be

obtained by calling 1 800 345 DELTA

(3358) or by contacting us by mail or online as follows (please include your model number and date of

original purchase):

Limited Warranty on Delta

Faucets

In the United States and Mexico: In Canada:

Delta Faucet Company Masco Canada Limited, Plumbing Group

Product Service Technical Service Centre

55 E. 111th Street 350 South Edgeware Road

Indianapolis, IN 46280 St. Thomas, Ontario, Canada N5P 4L1

Attention: Customer Solutions Attention: Customer Service

www.deltafaucet.com/service-parts/contact-us http://www.deltafaucet.ca/customersupport/assistance.html

Proof of purchase (original sales receipt) from the original purchaser must be made available to Delta Faucet Company for all warranty

claims unless the purchaser has registered the product with Delta Faucet Company or the product is a Delta

Recertified product purchased

from deltafaucet.com. This warranty applies only to Delta

faucets manufactured after January 1, 2019 and installed in the United States of

America, Canada and Mexico.

Limitation on Duration of Implied Warranties. Please note that some states/provinces (including Quebec) do not allow limitations

on how long an implied warranty lasts, so the below limitations may not apply to you. TO THE MAXIMUM EXTENT PERMITTED BY

APPLICABLE LAW, ANY IMPLIED WARRANTY, INCLUDING THE IMPLIED WARRANTIES OF MERCHAN

TABILITY AND OF FITNESS

FOR A PARTICULAR PURPOSE, IS LIMITED TO THE STATUTORY PERIOD OR THE DURATION OF THIS WARRANTY, WHICHEVER

IS SHORTER.

Limitation of Special, Incidental or Consequential Damages. Please note that some states/provinces (including Quebec) do not allow

the exclusion or limitation of special, incidental or consequential damages, so the below limitations and exclusions may not apply to you. TO

THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS WARRANTY DOES NOT COVER, AND DELTA FAUCET COMPANY

SHALL NOT BE LIABLE FOR, ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES (INCLUDING LABOR CHARGES TO

REPAIR, REPLACE, INSTALL OR REMOVE THIS PRODUCT), WHETHER ARISING OUT OF BREACH OF ANY EXPRESS OR IMPLIED

WARRANTY, BREACH OF CONTRACT, TORT, OR OTHERWISE. DELTA FAUCET COMPANY SHALL NOT BE LIABLE FOR ANY DAMAGE

TO THE FAUCET RESULTING FROM REASONABLE WEAR AND TEAR, OUTDOOR USE, MISUSE (INCLUDING USE OF THE PRODUCT

FOR AN UNINTENDED APPLICATION), FREEZING WATER, ABUSE, NEGLECT OR IMPROPER OR INCORRECTLY PERFORMED

INSTALLATION, MAINTENANCE OR REPAIR, INCLUDING FAILURE TO FOLLOW THE APPLICABLE INSTALLATION, CARE

AND

CLEANING INSTRUCTIONS. Notice to residents of the State of New Jersey: The provisions of this warranty, including its limitations, are

intended to apply to the fullest extent permitted by the laws of the State of New Jersey.

Additional Rights. This warranty gives you specific legal rights, and you may also have other rights which vary from state/province to state/

province.

This is Delta Faucet Company’s exclusive written warranty and the warranty is not transferable.

If you have any questions or concerns regarding our warranty, please contact us as provided above or view our Warranty FAQs at www.

deltafaucet.com.

Cleaning and Care

Care should be given to the cleaning of this product. Although its finish is extremely durable, it can be damaged by harsh abrasives or polish. To clean,

simply wipe gently with a damp cloth and blot dry with a soft towel.

Limpieza y Cuidado de su Llave

Tenga cuidado al limpiar este producto. Aunque su acabado es sumamente durable, puede ser afectado por agentes de limpieza o para pulir

abrasivos. Para limpiar su llave, simplemente frótela con un trapo húmedo y luego séquela con una toalla suave.

Instructions de nettoyage

Il faut le nettoyer avec soin. Même si son fini est extrêmement durable, il peut être abîmé par des produits fortement abrasifs ou des produits de

polissage. Il faut simplement le frotter doucement avec un chiffon humide et le sécher à l’aide d’un chiffon doux.
