Side 1/8
Contents
Di󰀨erent models
Di󰀨erent models 1
Introduction 1
Installation 2
Use, safety 3
Cleaning and hygiene 5
Fault nding 6
Maintenance 7
Conformity with regulations 8
• Beater-mixers of 60/80 litre
capacity with accessory hub, corrosion-proofed for meat
processing. Manual or electric controls.
• All of these models are also available in stainless steel.
identication plate attached to the frame.
This document is to be used in conjunction with the original manufacturer’s manual.
The symbols correspond with the numbered drawings of the original manual.
1.1a
1.1b
controls for the speed variator and the bowl cradle.
• Beater-mixers of 60/80 litre capacity with electric controls for
the speed variator and the bowl cradle.
• Beater-mixers of 60/80 litre capacity with accessory hub. Manual
or electric controls.
Introduction
1.1 DESCRIPTION
• These beater mixers are professional bakery - confectionery
machines for kneading, mixing and whisking all types of foods-
tu󰀨s. The models "A" are adapted for use in the kitchen and
can be used to drive accessories.
A Stainless steel bowl, 60/80 litre capacity
B Protective guard with removable spout and with
additional plastic screen
C Planetary gear
D Control panel
E Head
F Manual control for changing the speed
G Column
H Manual control for bowl cradle (BMX 60)
I Bowl locking knob
J Bowl cradle
K Leg
L Rubber foot
• There are 3 standard tools available as standard:
A A spiral hook for kneading dough.
B A paddle for mixing.
C A whisk for emulsifying.
•
Common optional equipment for the 60/80 l models "A":
- Strengthened 40 litre and 60 litre whisks for di󰀩cult work.
- Reduced bowl of 40 litre with 3 tools (60/80 l).
- Reduced bowl of 60 litre with 3 tools (80 l).
- 60 litre perforated paddle for light mixing.
- 40/60 litre mixer for mixing meat (meat processing).
- 60/80 litre bowl scraper.
- 60 and 80 litre bowl trolleys (supplied as standard with the 80l).
• Optional equipment for 60/80 l models "A" only:
- Machine accessories (see §3-5).
cutter, sieve.
11/2023
GB
Introduction
to work correctly and in complete safety, and is designed to make
below).
What follows is in no case intended to be a long list of warnings and
constraints, but rather a series of instructions meant to improve the
service provided by the machine in every respect, and particularly
result from inappropriate procedures for use and management.
installing, commissioning, using, maintaining, repairing or dis-
carefully before proceeding with the various operations, in order
result in damage to the machine or put people’s safety at risk.
It is just as important that the Manual should always be available
to the operator and it should be kept carefully where the machine
doubt, or in any case, whenever the need arises.
Manufacturer or approved After Sales Service provider, who is
constantly available to ensure quick and careful service for im-
proved machine operation and optimum e󰀩ciency.
Note that the safety, hygiene and environmental protection stan-
dards currently applicable in the country where the machine is
operation. Consequently it is the user’s responsibility to ensure
that the machine is operated and used solely under the optimum
safety conditions laid down for people, animals and property.
1 BMX 60/80 GB 06 2015
The reference language for these instructions is French.
2.1a-b
Installation
In the case of the machine being handled manually, take
all necessary precautions to avoid it tilting, especially
forwards (centre of gravity marked G).
(lifting points marked F).
2. DIMENSIONS - WEIGHT (for information only)1
A Gross weight packaged (kg).
B Net weight with equipment (kg).
C Dimensions of packaging (mm).
D Size of machine: L x W x H (mm).
• Handling - transport
- The beater is supplied packed on a wooden pallet.
2.1a
ATTENTION!!
Machine storage: -25°C to +50°C
Ambient temperature during operation: +4°C to +40°C
This machine is for professional use and must be used by sta󰀨 trained to use, clean and maintain it, in terms or reliability and safety.
Use the machine in adequately lit premises (See applicable technical standard for the country of use. In Europe, refer to standard
EN 12464-1)
When handling the machine, always check that the parts taken hold of are not mobile elements: risk of dropping and injury to the
lower limbs.
The machine is not designed for use in explosive atmospheres.
2.2 LOCATION
• To pack or level the machine (max. adjustment 10 mm):
spanner).
- Adjust the foot then lock in position.
2.
2
with the paddle.
• To anchor the machine or table to the ground:
- Counter drill the attachment holes of the feet (8 mm dia. screw
max., min. length 30 mm, rawl plugs not supplied).
2.3 ELECTRICAL CONNECTION
ATTENTION!!
Connection to the electrical power supply must be done according to proper professional practice by a qualied and authorised
person (see current standards and legislation in the country of installation).
If an adapter is used on the socket, a check must be made that the electrical characteristics of this adapter are not lower than
those of the machine.
Do not use multiple plugs
The AC power supply to the machine must comply with the following conditions EN60204-1;
- Maximum voltage variation: ±10%
- Maximum frequency variation: ±1% on a continuous basis, ± 2% over short periods
ATTENTION: the electrical installation must comply (for design, creation and maintenance) with the legal and standard
requirements in the country where used.
- Check that the electric mains voltage, the value shown on the specication plate.
- The machine’s electrical power supply must be protected against voltage surges (short-circuits and excess voltages) using a
circuit breaker compliant with IEC60947-2 properly sized, of the appropriate gauge relative to the place of installation and machine
specications – see the specications shown in column G of gure 2.3a
ATTENTION: Concerning protection against indirect contact (depending on the type of power supply provided and
connection of the exposed conductive parts to the equipotential protection circuit), refer to point 6.3.3 of EN 60204-1 (IEC
60204-1) with the use of protection devices for automatic shut-o󰀨 of power in the event of an insulation fault with a TN or
TT, system, or for the IT system, with the use of a permanent insulation or di󰀨erentials controller for automatic shut-o󰀨.
The requirements of IEC 60364-4-41, 413.1 must apply for this protection.
For example: in a TN or TT system, a di󰀨erential circuit breaker must be installed upline of the power supply, with a
suitable power cut-o󰀨 (e.g.: 30 mA) on the earthing installation for the place where it is planned to install the machine.
ATTENTION: Failure to comply with these instructions means the customer runs the risk of machine failure and/or acci-
dents due to direct or indirect contacts.
BMX 60/80 GB 11 2023 2
• The machine must be protected by a differential circuit
column G of the characteristics table.
• Check the direction of rotation:
- of the planetary gear, anti-clockwise (see arrow on head),
- or of the tool, in a clockwise direction .
• If the direction of rotation is inversed, change over the two
phase wires on the plug.
the operating instructions.
proceed as follows:
2.3a
2.3b
2.3c
3.1 OPERATION - SAFETY
• The safety of the user is guaranteed by:
standardised distance and stops the motor when lifted.
- The design of the guard, which allows products to be added in
mid-cycle in complete safety.
- The beater only starting if the cradle is in the raised work
position and the safety guard is lowered the bowl is in position
on the cradle.
- The START button needing to be pressed after stoppage (no
volt release).
overloading by means of thermal overloads.
• Control panel
a) (manual controls)
that marked on the rating plate.
• The machine must be protected by a differential circuit
column G of the characteristics table.
• Main motor characteristics:
A
B Number of phases (1 single phase or 3 three phase)
C Nominal voltage in volts (value, range or switching)
D Frequency (Hertz)
E Nominal output (Watts)
F Nominal current (Amperes)
G Size of the protection fuse for the electrical cable (Amperes)
with electric controls for the speed variation and for raising
table:
1) Three phase dual voltage motor
+ earth, as well as a corresponding waterproof plug with a 20 A
rating compliant with IEC60309 to be installed on the power cord.
The machine must be earthed with a green/ yellow wire.
Use, safety
2.3d
2.3a
3.1a
3.1b
(BMXE 60/80)
- Unplug the machine.
- Remove the rear plate and unclip the rear cover by pulling it.
- Check the electrical wiring diagram of the corresponding model.
- Change over the connector strips on the main motor connector
housing.
the primary winding from the 400 V terminal to the terminal
marked 230 V. To gain access to the transformer, remove the
screws retaining the mounting bracket (7 mm spanner).
motor (column F of the table).
Note: The control circuit always has a 230 V supply, the
coil of the contactors or other components do not need to
be changed.
• For the 60/80 l "E" models versions with electric controls:
housings.
- Set the current of the termal relays F2/F3 of the auxiliary motors.
(column F of the table).
- Request the corresponding thermal overloads.
- Check the operation and the direction of rotation.
- Ret the lower plate and rear cover.
2) Single phase motor
ground, rated at 16A in accordance with IEC60309, and a cor-
responding waterproof plug to be installed on the power cord.
• The direction of rotation is set in the factory.
This is due to the fact that the boards are tted with a grounding
standard appliance a ash test of 25 amps and up to 3000v is
used but, as you would expect, to use this on equipment, which
has a printed circuit, board would be quite destructive to that
board. We would recommend the use of a PAT tester approved
for computer systems which use a lower rate of amps.
two ways to get overcome this problem.
not needed.
2.3d
2.3b
b) (electric controls)
A STOP button
B Timer button
C Timer position, continuous OPERATION
D Bowl lighting knob
E START button
F Speed indicator LED
G Speed change handle (BMX 60)
H Button for increasing the speed
I Button for decreasing the speed
J Button for raising the bowl
K Button for lowering the bowl
{
Clean the machine properly prior to its rst use
Uncontrolled closure of the lid or ram press involves a risk of crushing the ngers.
Never put a hand in the ejection area while the machine is in operation; risk of injury. It is strictly forbidden to put the safety systems
out of action or modify them: Risk of permanent injury!!!!
Check that the safety devices operate correctly each time before using (see paragraph on «safety system adjustments»). Never
put a hand, a hard or frozen object in the appliance
For health and safety reasons, always use a washable or disposable strong head covering that covers the hair completely.
ATTENTION!!
BMX 60/80 GB 11 20233

Produkspesifikasjoner

Merke: Dito Sama
Kategori: Ikke kategorisert
Modell: 600180

Trenger du hjelp?

Hvis du trenger hjelp med Dito Sama 600180 still et spørsmål nedenfor, og andre brukere vil svare deg


Ikke kategorisert Dito Sama Manualer

Dito Sama

Dito Sama 600180 Bruksanvisning

11 August 2025
Dito Sama

Dito Sama 600137 Bruksanvisning

11 August 2025

Ikke kategorisert Manualer

Nyeste Ikke kategorisert Manualer

Kodak

Kodak C Ordinary Bruksanvisning

11 August 2025
Kodak

Kodak Professional DCS600 Bruksanvisning

11 August 2025
Teka

Teka FO 915 I Bruksanvisning

11 August 2025
Ambient Weather

Ambient Weather WS-04 Bruksanvisning

11 August 2025
Chamberlain

Chamberlain 041A5021-H-315 Bruksanvisning

11 August 2025
Chamberlain

Chamberlain 7708CB-P Bruksanvisning

11 August 2025
Ambient Weather

Ambient Weather WS-B1025C Bruksanvisning

11 August 2025
Ambient Weather

Ambient Weather F007PF Bruksanvisning

11 August 2025
RAM Mounts

RAM Mounts RAM-GDS-B-101LB-SAM21U Bruksanvisning

11 August 2025
Chamberlain

Chamberlain MYQ-SGC1WCH Bruksanvisning

11 August 2025
