Side 1/4
EN
Original Instructions
Version 1 – August 2024
29098
DIGITAL
BOX LEVEL
2. Specication
Stock No. 29098
Part No. DBL100
Measuring ranges 0 – 90°
0 – 180°
Auto shut down (approx.) 10 minutes
Operating/Storage temperature 0 – 50°C /<85%RH
Batteries required 2 × AAA 1.5V (not supplied)
Dimensions W 30 × H 68 × D 62mm
Net Weight (approx.) 100g
3. Health and Safety Information
Important: Read all the Health and Safety instructions before attempting to operate, maintain or repair this product.
Failure to follow these instructions may result in injury or damage to the user or the product.
• DO NOT use if the device is damaged in any way or evidence of battery leakage.
• When replacing the batteries check that they are tted in the correct +/- orientation.
• DO NOT disassemble or drop this device.
• DO NOT attempt to repair this device; it contains no user-serviceable parts.
• DO NOT use this product for purposes other than its intended use.
• DO NOT expose to high temperatures or humidity.
Read this manual in full before using this product and
retain it for future use. Always use the latest version of the
manual. Please visit drapertools.com/manuals for the
latest version.
1. Intended Use
This product is designed to measure or set angles and for
use as a digital level. Strong magnetic base to attach to
surfaces such as conduit, pipes, saw blades and vents.
Any other application beyond the conditions established
for use will be considered misuse. Draper Tools accepts no
responsibility for improper use of this product.
4. Identication
4.1 Product Overview
(1)
(5)
(2)
(3)
(4)
(1) Display screen
(2) Power/Zero button
(3) Magnetic base
(4) Hold/Range button
(5) Battery compartment
4.2 Display Overview
(B)
(G) (A) (G)
(C) (D) (E) (F)
(A) Measurement value
(B) Low battery
(C) Hold
(D) Zero
(E) Range setting (90°/180°)
(F) Inclination direction
(G) Degree angle
5. Operation
5.1 Fitting or Replacing the batteries
Requires 2 × AAA batteries (not supplied).
1. Unscrew the battery compartment cover.
2. Insert 2× AAA batteries.
− Check that the batteries are tted in the
correct +/- orientation.
3. Ret the battery compartment and secure with the
screw.
• Replace the batteries when the low battery symbol (B)
appears on the screen.
