Draytek Vigor 2500We Bruksanvisning
Les nedenfor 📖 manual på norsk for Draytek Vigor 2500We (27 sider) i kategorien Ruter. Denne guiden var nyttig for 3 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere
Side 1/27
1
DRAYTEK
VIGOR
2500
SERIES
2
ADSL Routers
Annex A / Annex B
ISDN Backup
Wireless AP
Vigpr2500
Vigpr2500We
Vigpr2500Wt
The Vigor2500 series is an Internet access solution for your LAN which not only provides shared
web surfing but countless other value-added features such as security, VPN and multimedia support,
all in a reliable one-box solution.
LED Indicators
and Back Panels
Each of the Vigor2500 series router has different front and rear panels. Before
you begin to install, please take a moment to become more familiar with the
LED indicators and rear panels. The following sections describe the models
individually.
Vigor2500
*
*/*
~
~
*
*/*
~
*
*
*/*
~
*
series introduction
3
Vigor2500
LED Indicators Descriptions
ACT(Activity)
ADSL
Blink when power is supplied to the router and the router is running normally.
LINE
DATA
ON when the ADSL network is correctly setup
Blinking indicates the DSL protocols start handshaking.The light will
remain still when data transmission is available.
Back Panels Descriptions
LAN 1-4
Link
100Mbps
Local Area Network port status. A steady LED indicates a
connection between computers on your LAN. A flickering LED
indicates data transmission.
Speed status of the Ethernet connection. A steady LED indicates
100Mbps speed. If the Link light is on and the 100Mbps light is off,
the speed is 10Mbps.
VPN
VPN connection status. A steady LED indicates VPN connection is up.
ON/OFF
PWR
ON / turn on power. OFF / switch off the power.
Only the power adapter comes with the package can be connected
to the AC 9V power jack.
To connect Vigor 2500 to an electrical outlet.
P1,P2,P3,P4
These switch ports should be connected to your local PCs.
ADSL
To connect the ADSL cable to your telephone jack.
Factory Reset
The restore default settings: While the router is running (ACT LED blinking), press the
button and hold for more than five seconds. The ACT LED begins to blink rapidly, then
release the button . The router will restart with the factory default configuration.
Produkspesifikasjoner
| Merke: | Draytek |
| Kategori: | Ruter |
| Modell: | Vigor 2500We |
