ETX Powered Loudspeakers

User Manual

ETX Powered Loudspeakers Table of contents | en 3

Electro-Voice

User Manual

2022-05 | 06 | F.01U.276.083

Table of contents

Safety 4

1.1 Important safety instructions 4

1.2 Suspension 5

1.3 Notices 6

1.4 FCC information 6

1.5 Precautions 6

Description 8

2.1 Quick setup 8

2.2 System features 9

System overview 11

3.1 Technical specifications 11

3.2 Dimension drawings 13

3.3 Frequency response graphs 15

Operation 17

4.1 Tripod and floor monitor operation 17

4.2 Suspension 21

4.3 Amplifier DSP controls 24

4.4 System status 26

4.5 DSP controls 27

4.5.1 Full-Range loudspeaker DSP control menu 28

4.5.2 Subwoofer DSP control menu 31

4.6 Recommended configurations 36

4.6.1 Daisy-chaining full-range systems 36

4.6.2 Using full-range systems as monitors 37

4.6.3 Stacking full-range systems with subwoofers 38

4.6.4 Subwoofer cardioid array 39

4.7 Removing the subwoofer caster wheels 41

Troubleshooting 42

Produkspesifikasjoner

Merke:	Electro-Voice
Kategori:	Subwoofer
Modell:	ETX-15SP
Strømkildetype:	AC
Pakkevekt:	46800 g
Materiale:	Stål
Antall subwoofere:	1
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Produktfarge:	Sort
Subwoofer-vekt:	41700 g
Subwoofer RMS-styrke:	1800 W
Subwoofer-driverdiameter (imperisk):	15 "
XLR i:	Ja
Frekvensomgang subwoofer:	32 - 180 Hz
Bredde subwoofer:	576 mm
Dybde subwoofer:	825 mm
Høyde subwoofer:	471 mm
Diameter på subwoofer-driver:	380 mm
Subwoofer-sensitivitet:	134 dB
