Owner’s Manual

TOC

Table of Contents .............................. TOC

Safety First ..................................... TOC

Product Description ...............................1

Welcome ...............................................1

Important Features ............................... 1

Model Summary ................................... 2

Packing List .......................................... 2

EVID

Product Family ......................... 3

Product Feature Identification .............. 3

SAM

(Strong-Arm-Mount

) System . 4

Step-by-Step Installation and Wiring .... 4

Step 1 - Mount the SAM

Bracket ..4

Step 2 - Select Wattage Tap (Models

4.2t and 6.2t Only)............................ 5

Step 3 - Mount the Speaker to the

SAM

Bracket ................................. 5

Step 4 - Wire the Speaker ................ 6

Step 5 - Secure the Seismic Tab

Connection Point .............................. 6

Step 6 - Test System Operation ....... 6

Packing List (12.1 Subwoofer) ............. 7

Product Feature Identification (12.1

Subwoofer) ...........................................7

Step-by-Step Installation and Wiring

(12.1 Subwoofer) .................................. 8

Step 1 - Mount the Bracket .............. 8

Step 2 - Install the Safety Line .........8

Step 3 - Wire the Speaker ................ 8

EVID

Owner’s Manual

Table of Contents

Step 4 - Mount the Speaker to the

Bracket ............................................. 9

Step 5 - Test System Operation .....10

Safety Agency Compliance ................ 10

Maintenance ....................................... 10

Uniform Limited Warranty ................... 11

Exclusions and Limitations ................. 11

Obtaining Warranty Service ............... 11

Incidental and Consequential Damages

Excluded ............................................. 11

Other Rights ....................................... 11

Speakers and Electronics .................. 11

Appendix A - Integrating the 12.1

Subwoofer .............................................12

Installation Examples ......................... 12

Using the 12.1 in Passive Mode ........ 12

Crossover Freq. and Impedance ....... 12

Using a Separate Amplifier Channel for

the 12.1 ...............................................12

Characteristics of All Subwoofers ......12

Appendix B - Painting the Speaker .... 13

Painting Process (3.2, 4.2, 6.2) ......... 13

Painting the Grille ............................... 13

Painting Process (12.1 Subwoofer) ...13

Appendix C - Troubleshooting Table .14

Appendix D - Technical Specs ............ 15

3.2/3.2t; 4.2/4.2t .................................15

6.2/6.2t; 12.1 ...................................... 16

Notes ......................................................17

Safety First

Suspending any object is potentially dangerous and should only be attempted by individuals who

have a thorough knowledge of the techniques and regulations of rigging objects overhead. Electro-

Voice® strongly recommends that all speakers be suspended taking into account all current national,

federal, state and local regulations. It is the responsibility of the installer to ensure that all speakers

are safely installed in accordance with all such regulations. When speakers are suspended, Electro-

Voice® strongly recommends that the system be inspected at least once a year. If any sign of

weakness or damage is detected, remedial action should be taken immediately. The user is

responsible for making sure that the supporting surfaces, and any additional hardware used, is

capable of supporting the loudspeaker. Any hardware used to suspend a loudspeaker array that is

not provided by/associated with Electro-Voice® is the responsibility of others.

EVID

Owner’s Manual

Product Description

Welcome

Thank you for purchasing EVID™ Series

loudspeakers. Read through this manual

to familiarize yourself with the features,

applications, and precautions before you

use these products.

EVID™ Series loudspeakers use

innovative design and materials to provide

premium-level performance from compact

surface-mount speakers.

Four models comprise the EVID™ Series:

the 6.2 with dual 6-inch LF drivers and a 1-

inch titanium tweeter with waveguide; the

4.2 with dual 4-inch LF drivers and a 1-

inch titanium tweeter with waveguide; the

3.2 with dual 3.5-inch LF drivers and a .75-

inch titanium direct radiator tweeter. The

EVID™ 12.1, a subwoofer designed to

augment and extend the full-range model’s

low-frequency response completes the

line.

Important Features

•Line-array enhanced coverage control

•Organic, unobtrusive shape

•SAM™ (Strong-Arm-Mount™) system

for secure and reliable mounting

•Extremely large speaker swing and

rotation ranges for flexible placement

and coverage everywhere

•Full bandwidth overload protection

•Weather resistant and paintable

•Dual LF transducers

•Extended bass

•Greater power handling and output

•Titanium HF transducers (4.2, 6.2

waveguide coupled)

•High sensitivity

•Shielded for video applications
