Assembly instructions (Original instructions)
8073237
2017-07
[8072273]
†‡
Sub- base
V - -S- ABS S7 G14
Festo SE & Co. KG
Ruiter Straße 82
73734 Esslingen
Germany
+49 711 347-0
www.festo.com
1. Further applicable documents
All available documents on the product www.festo.com/pk
2. Safety
•Switch off compressed air before mounting work.
3. Intended use
Connector between a solenoid valve VOFC/VOFD with a NAMUR port pattern
according to VDI/VDE 3845 Part 1:2010-09 and a NAMUR rib or NAMUR
column for lift drives.
4. Scope of delivery
23215d_1
1 Sub- base
VABS-S7-S- G14
2 Blanking plug
3
Screw
(1x)
(2
x)
(1x)
F or mounting
to a NAMUR rib
5. Not in scope of delivery
23215d_2
4 Solenoid valve
VOFC/VOFD
5 Mounting kit
Comprises:
6 Screw
7 O-rings
8 Threaded pin
(1x)
(1x)
(2
x)
(2x)
(1x)
23215d_8
9
Mounting bracket (1x)
For mounting to
a NAMUR column
Comprises:
aJ Mounting adapter
aA
Screw
(1
x)
(2x)
6. Mounting
23215d_7
•Screw both blanking
plugs 2 into the
thread . (A)
Observe the tightening
torque.
•Screw the threaded
pin 8 into the thread . (B)
23215d_10
For mounting to a NAMUR rib
•Push the screw 3 through
the drill hole (C).
23215d_9
For mounting to a NAMUR
column (alternative)
•Push the screws aA
through the drill holes . (D)
•Screw the screws into the
thread (E) of the mounting
adapter . aJ
23215d_5
Information
The solenoid valve 4can
also be mounted rotated
downwards by 180°.
•Press O- rings 7into the
depressions (C) of the
solenoid valve . 4
•Place the solenoid valve 4
on the sub- . base 1
23215d_6
•Tighten screws . 6
Observe the tightening
torque.
8
1
4
1
3.0 Nm
_
10 %
B
6
1
3
2
4
1
C
A
A
2
3
C
aA
aJ
D
E
7
7
10 Nm
_
10 %
9
aA
aJ
4
7
6
8
5
