Side 1/4
PN 602513
July 1996 Rev.3, 11/01
1996-2001 Fluke Corporation. All rights reserved. Printed in USA
15 PSID/G
PRESSURE MODULE
700
P
04
1 bar
100 kPa
RANGE
Low
High
Dierential
100 PSIG
PRESSURE MODULE
700
P
06
7 bar
700 kPa
RANGE
Gage
is1f.eps
Introduction
The Fluke 700PDX Series Pressure Modules measure
positive and negative pressure. The 700PVX modules
measure vacuum. The 700PDX modules work with the Fluke
700 Series Documenting Process Calibrators. The 700PVX
modules work only with the 740 Series Calibrators. Read this
sheet before you use the pressure module. This sheet
contains specifications and information about how to avoid
damaging the pressure module. See the calibrator’s Users
Manual for operating instructions.
Note
If you are using a Fluke-701 or Fluke-702, software
V1.3 or higher is required. See specification
footnote 1.
The pressure module measures pressure or vacuum using
an internal microprocessor. It receives operating power from
and sends digital information to the calibrator.
Gage pressure modules have one pressure fitting and
measure pressure with respect to atmospheric pressure.
Differential pressure modules have two pressure fittings and
measure the difference between the applied pressure on the
high fitting versus the low fitting. A differential pressure
module functions like a gage module when the low fitting is
open.
®
700 Series Dual-Range and
Vacuum Pressure Modules
Instruction Sheet
