May 2009
©2009 Fluke Corporation. All rights reserved. Specifications subject to change without notice.
All product names are trademarks of their respective companies.
1
80PK-10
Type K Thermocouple Pipe Clamp Temperature Probe
Instruction Sheet
Introduction
XWWarning
To avoid electric shock, do not
use this probe when voltages
exceeding 24 V ac or 60 V dc are
present. The probe is electrically
connected to the output terminals.
The 80PK-10 Type K Thermocouple Pipe Clamp
Temperature Probe (Figure 1) is designed to reliably
measure the temperature of pipes 1.25-inch (32 mm)
to 2.5-inch (64 mm) in diameter, at temperatures
between -29 °C and 149 °C (-20 °F and 300 °F),
while retaining a long service life.
Plunger
Sensor
V Notch
gcw01.eps
Figure 1. 80PK-10 Pipe Clamp Temperature Probe
Specifications
Measurement Range: -29 °C to 149 °C (-20 °F to
300 °F)
Accuracy: ±1.9 3.4 °C (± °F). Surface measurement
accuracy of ± °1.9 C includes ± °1.1 C variation in alloy
plus probe contact and shunting uncertainty of
± °0.8 C.
Repeatability: ±0.56 °C (±1 °F)
Output: @ 25 ° °C (77 F) = 1.00 mV (Reference
junction at 0 °C)
Seebeck Coefficient:
@ 25 °C (77 ° μ °F) = 40.50 V / C
Measurement Time (Time Constant):
0.5 seconds (5 time constants = 1 complete step
change, i.e. 2.5 seconds)
Maximum Voltage Rating: 24 V ac rms, or
60 V dc
Sensor Material: Chromel-Alumel
Cable Length: 40 inches (1 meter)
Cable Insulation: Material: PVC
Maximum Temperature: 105 ° °C (220 F)
Minimum Temperature: -29 ° °C (20 F)
Conductor: K Type AWG #24 stranded
Probe Body: PBT
Maximum Temperature: 149 ° °C (300 F)
Minimum Temperature: -29 ° °C (20 F)
Connector: Mini-thermocouple connector with
7.925 mm (0.312 in) pin spacing
Media Limitations: Must be compatible with
chromel, alumel, and PBT
