Side 1/8
CV200, CV300, CV400
CV201, CV301, CV401
ClirVu
IR Windows
Installation Guide
PN 4341125
May 2013
© 2013 Fluke Corporation. All rights reserved. All product names are trademarks of their respective companies.
English
CV200, CV300, CV400
ClirVu
IR Window
Installation Guide
Introduction
The Clir IR Window is a precision made accessory which, when accurately Vu
surface of a pe 1, 2, 3/12, 3, and 12 enclosures, or as appropriate. All models Ty
are for indoor and outdoor use.
Read and understand these instructions thoroughly before attempting to install
the units.
All of the items in Table 1 are available from Fluke.
Table 1. Clir sVu IR Window Model
Series Size Nema peTy
CV200 50 mm (2″) 4, 12
CV300 75 mm (3″) 4, 12
CV400 100 mm (4″) 4, 12
PN 4341125
May 2013
© 2013 Fluke Corporation. All rights reserved. All product names are trademarks of their respective companies.
3
2
4
1
43 6
7
8
5
1 2
Introduction
The ClirVu IR Window allows the exibility to inspect an electrical enclosure both
visually and with infrared. Use this accessory on the at surface of a Type 1, 2,
3/12, 3, and 4/12 enclosures, or as appropriate. All models are for indoor and
outdoor use. Table 1 is a list of the models available from Fluke.
Table 1. ClirVu IR Window Models
Model IR Window Size
CV200, CV201 50 mm (2 in)
CV300, CV301 75 mm (3 in)
CV400, CV401 100 mm (4 in)
How to Contact Fluke
To contact Fluke, call one of the following telephone numbers:
Technical Support USA: 1-800-44-FLUKE (1-800-443-5853)
Calibration/Repair USA: 1-888-99-FLUKE (1-888-993-5853)
Canada: 1-800-36-FLUKE (1-800-363-5853)
Europe: +31 402-675-200
Japan: +81-3-3434-0181
Singapore: +65-6799-5566
Anywhere in the world: +1-425-446-5500
Or, visit Fluke’s website at http://www.uke.com/irwindows.
To view, print, or download the latest manual supplement, visit
http://us.uke.com/usen/support/manuals.
