Side 1/2

FLUKE CORPORATION

EVERETT, WA USA

US PAT:

www.patentlabel.com/fluke

IM ING IR AG

THERMOMETER

VT 02

FLUKE CORPORATION

EVERETT, WA USA

US PAT:

ww patentlabel.com/flukew.

IM ING IR AG

THERMOMETER

VT 02

> 9 in / 23 cm≤ 9 in / 23 cm

5:12

VT02 VT04A, VT04

0 % 25 % 50 % 100 %75 %

VT04A/VT04

VT02

Visual IR Thermometer

VT02, VT04A, VT04

Quick Reference Guide

PN 4477229 April 2014



LCD Display



Rotating Lens Cover



Power On/Off and Menu



Visual Camera



Micro SD Memory card slot



Trigger for Image Capture



Tripod Mount



Battery Cover



Select/Enter



Micro USB Connector



Infrared Lens



Battery Charge Status LED

To view, print, or download the latest VT-series documents and software, visit:

www.uke.com/vtsmartview

www.uke.com/vtquickstart

www.uke.com/vtmanual

Power On and Off

2 sec.

Image Blending

Capture and Save

Menu Functions and Basic Navigation

Battery Charge Level

Up/Down to

Change Values

Select/Enter

Open Display

Yellow Highlight

Icon Description VT02

VT04A

VT04

View Stored images

• •

Emissivity

• •

Color Palette

• •

Background Temperature

• •

Hot and Cold Markers

• •

Temperature Units

• •

Clock (Time and Date)

• •

High/Low Temperature Alarm

•

Auto-Monitor Alarm

•

Time-Lapse Image Capture

•

Auto Off

•

LCD Brightness (low, medium, high)

•

Save in BMP Format

•

Factory Reset

•

First time use:

enter date and time

Visual Image Alignment Control

Near Mode

Far Mode

Grayscale (Black hot)

Grayscale (White hot)

High Contrast

Rainbow

Ironbow

Hot Metal (VT04A, VT04 only)

Measurement Display

Color Palette

SD Card

No SD card in slot

SD card error

SD card empty

SD card full

Center-point

Measurement

Center-point Cursor

Blend Icon

Battery Status

Emissivity

Color Palette

Center-point

Measurement Area

Note

Use the micro SD memory card to download images from the Product to a PC. The micro-

USB cable is for battery charging only.

VT04

only

Produkspesifikasjoner

Merke:	Fluke
Kategori:	klimatermometer
Modell:	VT04
Vekt:	350 g
Bredde:	75 mm
Dybde:	55 mm
Høyde:	210 mm
Strømkilde:	Batteri
Plassering:	Hånd
Nøyaktighet:	2 °C
Sertifisering:	EN 61326:2006, IEC/EN 61010-1:2010
Batterilevetid:	8 timer
Klokkefunksjon:	Ja
Produktfarge:	Black, Yellow
Antall støttede batterier:	1
Skjermtype:	Digitalt
Batterispenning:	3.6 V
Driftstemperatur (T-T):	-5 - 45 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 60 °C
Modell/Type:	Infrarødt miljøtermometer
Driftshøyde:	0 - 2000 m
Temperature measuring units:	F, °C
Relativ luftfuktighet under drift (H-H):	10 - 90
Bæretaske:	Ja
Intervall for temperaturmåling:	-10 - 250 °C
Temperatur måleområde:	14 - 482 °F
Display formfaktor:	Rektangulær
Spektral respons:	6.5 - 14 µm
