Side 1/2

SUBWOOFERS

 CS-SW100 CS-SW120 CP-SW100 CP-SW120

PeakPower(Watts) 800 1000 1000 1300

RatedPower(Watts) 200 250 250 325

FrequencyResponse 33Hz-1.2kHz 27Hz-1kHz 30Hz-1.2kHz 24Hz-1kHz

Impedance 4Ohms 4Ohms 4Ohms 4Ohms

Sensitivity 87dB 88dB 88dB 89dB

ConeMaterial PressedPaper PressedPaper PressedPaper PressedPaper

VoiceCoilType RoundWound RoundWound RoundWound RoundWound

 Copper Copper Copper Copper

MountingDepth 120mm(4-23/32”) 136mm(5-11/32”) 142mm(5-19/32”) 154mm(61/16”)

MountingDiameter 228mm 277mm 228mm 277mm

 (9”) (1015/16”) (9”) (1015/16”)

CS-SW100 CS-SW120 CP-SW100 CP-SW120

SPEAKER PARAMETERS

www.fusionelectronics.com

INSTALLATION GUIDELINES

Ensuretheaudiosystemisturnedoffbeforemakinganyconnectionstotheamplier,speakersorsourceunit.

Failuretodosocouldresultinpermanentdamagetotheaudiosystem.

Whenwiringthesubwooferensurethatthewireisprotectedfromsharpobjectsandalwaysuserubber

grommetswhenwiringthroughmetalpanels.Ensureallterminalsandconnectionsareprotectedfromthe

vehiclechassisandfromeachotherasfailuretodosocouldresultinpermanentdamagetotheaudiosystem.

Whenconnectingtheamplierandsubwooferensureyouconnectthepositiveandnegativeoutputwirefrom

theampliertothecorrespondingsubwooferterminals.

1) Ensurethereisadequateclearanceanddepthforthesubwoofertobemounted

2) Markout&cutthecorrectdiameterhole

3) Drilltheholesforthemountingscrews

4) Insertthesubwooferandafxwiththeappropriatescrews

PORTED CS-SW100 CS-SW120 CP-SW100 CP-SW120

Volume(Litres) 30.0 50.0 25.0 50.0

Volume(cu.ft.) 1.06 1.77 0.88 1.77

PortDiameter 58.8mm(2”) 76.2mm(3”) 58.8mm(2”) 76.2mm(3”)

PortLength 241mm(9-1/2”) 250mm(9-27/32”) 290mm(11-13/32”) 225mm(8-7/8”)

TunedFrequency(Hz) 35.5 33.6 40.2 36.6

SEALED

Volume(Litres) 15.0 25.7 15.0 25

Volume(cu.ft.) 0.53 0.91 0.53 0.88

TunedFrequency(Hz) 56.27 51.9 62.8 61.4

OPTIMUM ENCLOSURES

PUBLISHEDBYFUSIONELECTRONICSLIMITED:©Copyright2010byFUSIONElectronicsLimited.Allrightsreserved.Specicationsanddesignaresubjecttochangewithoutnotice.

YOUCANHELPPROTECTTHEENVIRONMENT!Pleaseremembertorespectthelocalregulations:Handinthenon-workingelectricalequipmenttoanappropriatewastedisposalcenter.

RECORD YOUR PURCHASE DETAILS HERE:

SERIALNUMBER

DATEOFPURCHASE

AFFIXRECEIPTHERE

WARNING:AudioSystemscanproducesoundlevelsover135dB.Continuousexposuretosoundpressurelevelsover100dBmaycausepermanent

hearingloss!Pleasewatchforemergencyvehiclesaswarningsignalsmaynotbeheard.USECOMMONSENSE!

Forfurtherproductandinstallationinformation,pleasevisitwww.fusionelectronics.com

Pourplusd’informationssurlesproduitsetl’installation,rendez-voussurwww.fusionelectronics.com

Paraobtenermásinformaciónacercadelosproductosydesuinstalación,visiteelsitiowebwww.fusionelectronics.com

Bezoekwww.fusionelectronics.comvoormeerproduct-eninstallatie-informatie.

WeitereProdukt-undInstallationsinformationenndenSieunterwww.fusionelectronics.com

Perulterioriinformazionisuiprodottielaloroinstallazione,potetevisitarewww.fusionelectronics.com

Для получения дополнительной информации о продуктах и установке зайдите, пожалуйста, на: www.fusionelectronics.com

Produkspesifikasjoner

Merke:	Fusion
Kategori:	Bilhøyttaler
Modell:	CS-SW100
Produkttype:	Subwoofer-driver
Bredde:	- mm
Dybde:	- mm
Høyde:	- mm
Diameter:	269 mm
Mekanisk Q-faktor (Qms):	7.376
Elektrisk Q-faktor (Qes):	0.493
Total Q-faktor (Qts):	0.462
Forskyvningsvolum:	356 cm³
Subwoofer RMS-styrke:	200 W
Frekvensomgang subwoofer:	33 - 1200 Hz
Subwoofer-sensitivitet:	87 dB
Subwooferens toppeffekt:	800 W
Subwoofer-impedans:	4 Ω
Subwoofer-driverens membranmateriale:	Papir
Kraftfaktor (BI):	12.703
