Side 1/2

FPO-11

Puls oximeter

Introduction:

The Fysic FPO-11 is a pulse Oximeter which

measures the percentage of the amount of oxy-

gen found in the blood.

Intended use:

The Pulse Oximeter is a non-invasive device

intended for spot checking of functional oxygen

saturation of arterial hemoglobin (SpO2) and

pulse rate (PR). This portable device is indicated

for use in adult patients in clinical institution and

home environments.

Measuring principle:

By shining an infra-red light through the skin, the

reected light will be compared with the emitted

light which will in turn analyze the color of the red

blood cells. This colour measured will reect the

amount of oxygen in the blood.

Do not use:

Do not use the FPO-11 with an irregular heart

beat (Atrial Fibrillation).

Installation:

The FPO-11 comes with two included batteries, a

wrist strap and a protective case.

Install batteries:

1. Slide the battery cover o󰀨 of the FPO-11

2. Insert the two

supplied batte-

ries, be sure to

take note of the positive and negative poles

(+ and -)

3. Place the battery cover back onto the FPO-11

Fastening the wristband:

1. Push the thin cord through the

hole on the FPO-11 and then

make a loop from the cord.

2. Put the thick part of the strap through the loop.

3. Pull the thick part of the cord all the way

through the loop tugging slightly to tighten it.

Use:

Preparations & tips:

• Make sure that you are familiar with the ope-

ration of the pulse Oximeter.

• Avoid bright lights.

• Remove articial nails and/or nail polish.

• Wash your hands before using.

• Make sure your hands are warm to ensure a

good blood circulation.

• Sit quietly before and during the taking of the

measurement.

Measurement:

1. Open the clip and place your nger on the

FPO-11 with the nail facing upwards, as

shown on the adjacent picture; use your mid-

dle nger preferably pushing it gently towards

the back of the Oximeter.

2. Turn on the FPO-11 by pressing the

on/o󰀨 button.

3. If necessary, the reading direction

of the display can be changed by

pressing the on/o󰀨 button repea-

tedly.

4. Do not move your nger during the measurement.

5. Readings in the display:

- The “% SpO2” shows the percentage of

oxygen in the blood.

- The “PRbpm” gives the pulse rate of the

pulse per minute.

- The PI (Perfusion Index) is the ratio of the

pulsatile blood ow to the non-pulsatile

blood ow. The PI’s values range from

0.02% for very weak pulses to 20% for

strong pulses.

- Depending on the selected reading di-

rection, a pulsating bar graph shows the

strength of the heartbeat or the heart rate

can be seen at the bottom of the display.

6. The FPO-11 will turn o󰀨 15 seconds after the

clip has been taken o󰀨 the nger.

Setting an alarm:

You can set alarm tones to give alert signals when

the level of the oxygen in your blood, or the pulse

rate exceeds the adjustable upper or lower values.

1. Turn on the FPO-11 by quickly pressing the

on/o󰀨 button.

2. Hold down the on/o󰀨 button for more than one

second to open the settings menu.

3. Now release the on/o󰀨 button. You will see

one of the following statements:

• The line with the star at the end is the active line.

• Press quickly on the on/o󰀨 button to move the

star to the next line.

• Press and hold the on/o󰀨 button to change

the setting of the current line.

Limit Setup *

SPO2 Hi 100

SPO2 Lo 94

PR Hi 130

PR Lo 50

+/- +

Exit

Remind Setup *

Sound Reminder on

Beep o󰀨

Demo o󰀨

Restore Ok

Brightness 4

Exit

Produkspesifikasjoner

Merke:	Fysic
Kategori:	hjertmåler
Modell:	FPO-11
Strømkildetype:	Batteri
Nøyaktighet:	2 bpm
Batteritype:	AAA
Produktfarge:	Sort
Antall støttede batterier:	2
Batterispenning:	1.5 V
Display:	OLED
Oksygenmetning måleområde:	0 - 100
Puls måleområde:	25 - 250 bpm
Nøkkelbånd:	Ja
