Side 1/128

When you installing AGP card, please make sure the following

notice is fully understood and practiced. If your AGP card has

"AGP 4X/8X(1.5V) notch"(show below), please make sure your AGP

card is AGP 4X/8X(1.5V).

Caution: AGP 2X(3.3V) card is not supported by VIA

KT400. You

might experience system unable to boot up normally. Please insert

an AGP 4X/8X(1.5V) card

Example 1: Diamond Vipper V770 golden finger is compatible with

2X/4X mode AGP slot. It can be switched between AGP 2X(3.3V) or 4X

(1.5V) mode by adjusting the jumper. The factory default for this card is

2X(3.3V).

The GA-7VAX/GA-7VAXP (or any AGP 4X only) motherboards might not

function properly, if you install this card without switching the jumper to

4X(1.5) mode in it.

Example 2: Some ATi Rage 128 Pro graphics cards made by “Power

Color”, the graphics card manufacturer & some SiS 305 cards, their

golden finger is compatible with 2X(3.3V)/4X(1.5V) mode AGP slot, but

they support 2X(3.3V) only. The GA-7VAX/GA-7VAXP (or any AGP

4X only) motherboards might not function properly, If you install this

card in it.

Note : Although Gigaby te's AG32S(G) graphics card is based on

ATi Rage 128 Pro chip, the design of AG32S(G) is compliance

with AGP 4X(1.5V) specification. Therefore, AG32S (G)will work

fine with VIA

KT400 based motherboards.

Before you install PCI cards, please remove the Dual BIOS

label from PCI slots if there is one.

AGP 4X/8X notch

Produkspesifikasjoner

Merke:	Gigabyte
Kategori:	Hovedkort
Modell:	GA-7VAXP
Bredde:	305 mm
Dybde:	244 mm
Strømkildetype:	ATX
Antall USB 2.0-porter:	2
Hodetelefonutganger:	1
Maksimalt internminne:	3 GB
Forhåndsinstallert programvare:	Adobe Acrobat Reader\nAdobe Acrobat e-Book Reader\nNorton Internet Security
Lydbrikke:	Realtek ALC650
Komponent for:	PC
LAN-kontroller:	Realtek RTL8100B(L)
Støttede minnetyper:	DDR-SDRAM
Hovedkort formfaktor:	ATX
Antall minnespor:	3
BIOS-type:	AMI
USB 2.0-tilkoblinger:	2
Antall COM-porter:	2
Antall parallelle ATA-tilkoblinger:	4
Mikrofon, linje-inn-støpsel:	Ja
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
prosessorprodusent:	AMD
Antall PS/2-porter:	2
Kompatible prosessorserier:	AMD Athlon, AMD Athlon XP
Prosessorstøpsel:	Socket A(462)
Ethernet-grensesnittype:	Raskt Ethernet
BIOS minnestørrelse:	4 Mbit
Støttede minneklokkehastigheter:	200,266,333 MHz
Systemkort kretsoppsett:	VIA KT400
Hovedkort-chipsettfamilie:	VIA
Lyd-utgang kanaler:	5.1 kanaler
On-board grafikkort:	Nei
Diskettstasjonstilkobling:	Ja
PCI-slots:	5
Drivere medfølger:	Ja
Nettverksgrensesnitt:	Raskt Ethernet
Støtter parallellprosesseringsteknologi:	Støttes ikke
Antall IEEE1394-tilkoblinger:	3
AGP x8 slots:	1
Hovedkort-southbridge:	VIA 8235
