Programmable AC/DC Power Source

ASR-3000 Series

USER MANUAL

Rev. I

ISO-9001 CERTIFIED MANUFACTURER

This manual contains proprietary information, which is protected by

photocopied, reproduced or translated to another language without

prior written consent of Good Will company.

The information in this manual was correct at the time of printing.

However, Good Will continues to improve products and reserves the

rights to change specification, equipment, and maintenance

procedures at any time without notice.

Good Will Instrument Co., Ltd.

No. 7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan.

    Table of Contents
3
Table of Contents
SAFETY INSTRUCTIONS ................................................... 5
GETTING STARTED .......................................................... 9
ASR-3000 Series Overview ...................................... 10
Appearance ............................................................ 18
Theory of Operation ............................................... 27
OPERATION .................................................................. 36
Set Up .................................................................... 38
Menu Tree ............................................................. 61
Basic Operation ...................................................... 66
Advanced Settings ................................................ 106
External Keypad Operation ................................... 114
EXTERNAL CONTROL .................................................... 115
Using External Control I/O .................................... 116
Using External Signal Input Function .................... 117
Compiling Arbitrary Waveform Input .................... 122
MISCELLANEOUS ......................................................... 132
T Ipeak, hold ........................................................ 133
IPK CLR ................................................................ 135
Power ON ............................................................ 136
Buzzer .................................................................. 138
Remote Sense ...................................................... 139
Slew Rate Mode ................................................... 142
Output Relay ........................................................ 145
THD Format ......................................................... 146
External Control ................................................... 148
V Unit .................................................................. 149
ACin Detection ..................................................... 150
