GW Instek GDS-307 Bruksanvisning

Les nedenfor 📖 manual på norsk for GW Instek GDS-307 (188 sider) i kategorien Ikke kategorisert. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Side 1/188
Compact Digital Storage
Oscilloscope and Digital
Multimeter
GDS-200 and GDS-300 Series
USER MANUAL
GW INSTEK PART NO. 82DS-22000EA1
ISO-9001 CERTIFIED MANUFACTURER
This manual contains proprietary information, which is protected by
copyright. All rights are reserved. No part of this manual may be
photocopied, reproduced or translated to another language without
prior written consent of Good Will company.
The information in this manual was correct at the time of printing.
However, Good Will continues to improve products and reserves the
rights to change specification, equipment, and maintenance
procedures at any time without notice.
Good Will Instrument Co., Ltd.
No. 7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan.
SAFETY INSTRUCTIONS
3
Table of Contents
SAFETY INSTRUCTIONS ................................................... 5
GETTING STARTED ......................................................... 10
GDS-200 and GDS-300 Series Overview 12
Appearance .......................................... 15
Initial Setup ......................................... 30
OPERATION .................................................................... 37
Gesture Control ................................... 41
Common Menu UI Elements ................ 47
Vertical Menu Operation ...................... 50
Trigger Menu Operation ....................... 66
Trigger Setting ..................................... 68
Run Mode ............................................ 80
Cursor Measurements .......................... 83
Automatic Measurements .................... 86
Drop-Down Menu ................................ 94
Utility Menu ......................................... 96
Acquire Menu .................................... 107
Display Menu ..................................... 112
Go-NoGo Menu ................................. 118
Save Operations ................................ 124
Recall Operations .............................. 135
File Manager ...................................... 139
DMM Mode ....................................... 143
EE APPs ............................................. 154
REMOTE CONTROL CONFIG ......................................... 164
Interface Configuration ...................... 165
FAQ ............................................................................... 171
