Side 1/5

HDMI HDBaseT Extender over single Cat5e/6/7-100m

User manual

Thank you for purchasing this product. For optimum performance and safety, please read the instructions carefully

and keep the manual for future reference.

Please read below safety instructions carefully before installation and operation:

 Please pay attention to all the warnings and hints on this device.

 Do not expose this unit to rain, moisture and liquid.

 Do not put any stuff into the device.

 Do not repair or open this device without professional people’s guidance.

 Make sure good ventilation openings to avoid product overheating damage.

 Shut off power and make sure environment is safe before installation.

 Do not plug-in/out the connected cables when it is in using.

 Make sure the specification matched if using 3rd party DC adapters.

1.Introduction

This HDBaseT single network cable extender transmits HDMI signal up to 100meters over cat6 fluently and clearly.

It is lossless in signal and supports 3D, 24bits deep color, 4kx2k, CEC and HDCP.

2.Features

1. Apply HDBaseT extend technology

2.Uncompressed HDMI video signal

3. Support full HD 1080P@60Hz, 3d, 4kx2k@60Hz

4. Extend 1080p signal over cat6a up to 100 meters

5. Support bi-directional IR pass back

6. support HDCP ,CEC, 24 deep color

7. Support uncompressed LPCM audio and compressed DTS-HD, Dolby True HD

8. Can be powered by network cable. It only needs to input 12V power for either transmitter or receiver for

normal working.

Produkspesifikasjoner

Merke:	HELGI
Kategori:	AV-forlenger
Modell:	HI0375-100
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Maksimal oppløsning:	3840 x 2160 piksler
Maksimal oppdateringshastighet:	60 Hz
Materiale:	Metall
AC-inngangsspenning:	12 V
Mottakervekt:	107 g
Produktfarge:	Sort
Pakketype:	Boks
Strømforbruk (vanlig bruk):	8 W
Støttede videofunksjoner:	480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 1440p, 2160p
Modell/Type:	AV-sender og -mottaker
RJ-45-inngangsporter:	1
Lydsystem:	Stereo
Ethernet/bredbåndsforbindelse:	Ja
AC-adapter bunt:	Ja
Strøm over Ethernet (PoE):	Ja
Innput-strøm:	2 A
Maksimal overføring avstand:	100 m
Kabeltyper som støttes:	Cat5e, Cat6, Cat6a, Cat7
Trådløs mottaker (B x D x H):	66.5 x 98.5 x 23 mm
Senderdimensjoner (BxDxH):	66.5 x 98.5 x 23 mm
Sendervekt:	79 g
RJ-45-utgangsporter:	1
IR-mottaker inkludert:	Ja
IR blaster inkludert:	Ja
