User Manual

HDbitT 1 to 8 HDMI Fiber Optics

Extender Splitter

Output Port

8 x SC/APC

Specification

HDMI Signal

HDMI1.4, compatible with HDCP1.4

Support Resolutions

480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz,

720p@50/60Hz, 1080i@50/60Hz, 1080p@50/60Hz,

4K×2K@25/30Hz

DDC Signal Voltage

Items

Transport Protocol

HDbitT

Transmit Distance

Up to 10Km transmission distance for 4K×2K@25/30Hz

resolution over single mode optical fiber cables

5Vp-p(TTL)

Input Port

1 x HDMI

Working temperature

0~60°C

Power adapter

DC5V/2A

TMDS Bandwidth

10.2Gpbs

Fiber Optics Type

G657

4Kx2K

The product name and brand name may be registered trademark of related

manufacturers.TM and ® may be omitted on the user manual. The pictures

on the user manual are just for reference,and there may be some slight

difference with the real products.

We reserve the rights to make changes without further notice to a product

or system described herein to improve reliability, function or design.

Disclaimer

Q: TV display“waiting for connection...” on the bottom right corner?

A: 1)Please check if the power supply of extender slitter and RX(receiver)

is well connected and the power indicator led lights on.

2)Make sure all cables are firmly connected.

Q: TV display“Please check the TX input signal”?

A: 1) please check if there is an HDMI signal input of extender slitter

2) Try to connect the signal source directly to display device to see if

there is signal output from source device or change the signal source,

HDMI cables and try again.

Q: Display not fluent and stable

A: 1) Please check the cable length between extender slitter and RX(receiver)

is within the required range.

2) Press“reset”button on the extender slitter/RX panel, reset and

reconnect.

• FAQ

• Specification

Power Consumption

≤10W

Dimension

482.6(W)x 122.9 (D) x44.4 (H) mm

Weight

Color

Black

1.30Kg

Produkspesifikasjoner

Merke:	HELGI
Kategori:	AV-forlenger
Modell:	HLG0318-4K-FC
Vekt:	1300 g
Bredde:	482.6 mm
Dybde:	122.9 mm
Høyde:	44.4 mm
LED-indikatorer:	Power, Status
Bruksanvisning:	Ja
Oppløsning:	3840 x 2160 piksler
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Maksimal oppløsning:	3840 x 2160 piksler
Videokomprimeringsformater:	H.264
HDCP:	Ja
Maksimal oppdateringshastighet:	60 Hz
HDMI-versjon:	1.4
Utgangsstrøm:	5 V
HDMI inn:	1
HDCP-versjon:	1.4
Driftsspenning:	5 V
Fiberoptisk kontakt:	SC
Antall videoporter:	1
Produktfarge:	Sort, sølv
HD-type:	4K Ultra HD
Støttede grafikkoppløsninger:	1280 x 720 (HD 720),1920 x 1080 (HD 1080),2560 x 1440,3840 x 2160
Pakketype:	Boks
Strømforbruk (vanlig bruk):	10 W
Støttede videofunksjoner:	480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 1440p, 2160p
Driftstemperatur (T-T):	0 - 60 °C
Modell/Type:	AV-sender og -mottaker
Kroppsmateriale:	Aluminium
DC-inngangskontakt:	Ja
Lydsystem:	Stereo
AC-adapter bunt:	Ja
Plugg inn og spill:	Ja
Største båndbredde for port:	10.2 Gbit/s
Enkel installering:	Ja
Maksimal overføring avstand:	10000 m
Maksimal opereringsrekkevidde:	1000 m
Display Data Channel (DDC) inngang:	5 V
Video tilkoblingstype:	HDMI
Overgang Minimert Differential Signal (TMDS) inngang:	1.5 V
