I-PRO WV-S35402-F2L1 Bruksanvisning

I-PRO Sikkerhetskamera WV-S35402-F2L1

Les nedenfor 📖 manual på norsk for I-PRO WV-S35402-F2L1 (48 sider) i kategorien Sikkerhetskamera. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/48

(

)

Web Guide

WV-X35402-F2LM/ WV-X35302-F2LM

WV-X35402-F2L/ WV-X35302-F2L

WV-S35402-F2L/ WV-S35302-F2L

Ver 1.0

Contents

1. 　 Set up ……………………………………………………………………… 1

1.1 　 Install using Base Bracket …………………………………………………… 1

2. 　 Connect to the camera …………………………………………………… 2

2.1 　 IP Setting Software ………………………………………………………… 2

2.2 　 Access the camera …………………………………………………………… 2

2.3 　 About Live image pages ……………………………………………………… 4

3. 　 Set the camera …………………………………………………………… 6

3.1 　 Check whether the object is of the proper size. …………………………… 6

3.2 　 Adjust the image quality ……………………………………………………… 6

3.2.1 　 Set the light intensity control mode depending on the installation location and

installation area. …………………………………………………………… 6

3.2.2 　 Set white balance depending on the lighting environment you install. …… 7

3.2.3 　 Sets night time black-and-white switching mode ………………………… 8

3.3 　 Recording setting (SD Memory Card) ……………………………………… 9

3.3.1 　 Install the SD Memory Card ………………………………………………… 9

3.3.2 　 Record using SD Memory Card …………………………………………… 9

3.3.3 　 Play back images stored on the SD Memory Card ………………………… 9

3.4 　 Adjust the zoom ……………………………………………………………… 10

3.5 　 Hide some of the images …………………………………………………… 10

3.6 　 Identify sounds with AI ……………………………………………………… 11

3.7 　 Record sound ………………………………………………………………… 11

3.8 　 Set up events ………………………………………………………………… 11

3.8.1 　 Detect object movements ………………………………………………… 12

3.9 　 Enhance communication security …………………………………………… 13

3.10 　 Detect data falsification …………………………………………………… 13

3.11 　 Set the Image capture size and frame rates ……………………………… 13

3.12 　 Set the overlay image function …………………………………………… 13

Contents

3.13 　 Set the image stream ……………………………………………………… 14

3.13.1 　 About the Setting of Stream ……………………………………………… 14

3.13.2 　 About delivery volume control (bit rate) ………………………………… 14

3.13.3 　 Reducing Data Capacity with Smart Coding ……………………………… 15

3.14 　 i-PRO Configuration Tool (iCT) …………………………………………… 16

4. 　 Clean up …………………………………………………………………… 17

4.1 　 Cleaning of lenses …………………………………………………………… 17

4.2 　 Cleaning of Dome covers …………………………………………………… 17

5. 　 Specifications ……………………………………………………………… 18

5.1 　 PC environment required …………………………………………………… 18

5.2 　 About Image capture mode and Image capture size ………………………… 18

5.2.1 　 Image capture size ………………………………………………………… 19

5.2.2 　 Symbol restrictions ………………………………………………………… 21

5.3 　 DORI ………………………………………………………………………… 22

5.4 　 Delivery performance ………………………………………………………… 22

5.5 　 About Available Extension software ………………………………………… 22

5.6 　 Lamp ………………………………………………………………………… 24

5.6.1 　 Lighting of the lamp ………………………………………………………… 24

5.7 　 Button ………………………………………………………………………… 26

5.8 　 Cable ………………………………………………………………………… 27

6. 　 Other ……………………………………………………………………… 28

6.1 　 Initialize ……………………………………………………………………… 28

6.2 　 Check the software version ………………………………………………… 28

6.3 　 Order of setting when adjusting image quality ……………………………… 29

6.4 　 Adjusting object brightness (bright scenes) ………………………………… 29

6.4.1 　 Adjusting brightness ………………………………………………………… 29

6.5 　 Adjusting object brightness (dark scenes) …………………………………… 30

6.5.1 　 Adjust the maximum gain …………………………………………………… 30

6.5.2 　 Adjust the maximum shutter ……………………………………………… 30

6.6 　 Reducing white flickering and blacking on the screen ……………………… 31

6.6.1 　 Set Super Dynamic ………………………………………………………… 31

6.6.2 　 Set the backlight compensation …………………………………………… 32

Contents

Produkspesifikasjoner

Merke:	I-PRO
Kategori:	Sikkerhetskamera
Modell:	WV-S35402-F2L1
Vekt:	475 g
Bredde:	109 mm
Dybde:	119 mm
Høyde:	53 mm
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Maksimal oppløsning:	2688 x 1520 piksler
Videokomprimeringsformater:	H.264, H.265
Strømkildetype:	PoE
Antall kameraer:	1
HTTPS-kryptering:	Ja
Sertifisering:	UL (UL62368-1), c-UL (CSA C22.2 No.62368-1), CE, IEC62368-1, UL (UL62368-1), c-UL (CSA C22.2 No.62368-1), CE, IEC62368-1
Optisk zoom:	4 x
Innebygd mikrofon:	Ja
Hvitbalanse:	ATW, AWC
Nettleser:	Ja
Støyreduksjon:	Ja
Nettverksstandard:	IEEE 802.3af
Antall brukere:	14 bruker(e)
Lyddeteksjon:	Ja
Strømforbruk:	180 mA
Antall linser:	1
Antall sensorer:	1
Antall effektive piksler (H x V):	5.12 x 3.84 piksler
Personvern:	Ja
Linsesynsvinkel, horisontal:	121 °
Linsesynsvinkel, vertikal:	91 °
Bildefrekvens:	30 fps
Sensortype:	CMOS
Støttede lydformater:	AAC-LC, ADPCM, G.711, G.726
Produktfarge:	Black, White
Vippevinkelområde:	0 - 90 °
Minnekortenhet:	MicroSDHC, MicroSDXC
Støttede grafikkoppløsninger:	320 x 180,320 x 288 (QVGA),640 x 360,640 x 480 (VGA),1280 x 720 (HD 720),1280 x 960,1920 x 1080 (HD 1080),2048 x 1536 (QXGA),2560 x 1440
Zoomfunksjon:	Ja
Driftstemperatur (T-T):	-40 - 50 °C
Innebygd kortleser:	Ja
Lukkerhastighet:	1/10000 - 16/25 s
nattsyn:	Ja
IK-kode:	IK10
Formfaktor:	Kuppel
CCD-sensorstørrelse:	1/2.8 "
Strømforbruk (Power over Ethernet (PoE)):	8.6 W
Modell/Type:	IP-sikkerhetskamera
Kroppsmateriale:	Aluminium, Resin
Panoreringsomfang:	-45 - 45 °
Internasjonal beskyttelses (IP)-kode:	IP66
Bithastighetskontroll:	Constant Bit Rate (CBR), Variable Bit Rate (VBR)
Antall maskeringsområder for personvern:	8
Minimumsbelysning:	0.06 lx
Ethernet/bredbåndsforbindelse:	Ja
Ethernet-grensesnittype:	Raskt Ethernet
Relativ luftfuktighet under drift (H-H):	10 - 100
Støttede plasseringer/plasseringer som kan benyttes:	Utendørs
Totale megapiksler:	4 MP
Maksimal størrelse på hukommelseskort:	512 GB
Støttede Mac operativsystemer:	Mac OS 8.0
Privacy maske:	Ja
Effektiv distanse for nattsyn:	14 m
Fast fokalobjektiv:	2.4 mm
Maksimal blenderåpning:	2.1
Intelligent Video Surveillance (IVS)-systemfunksjoner:	Face detection, Human detection, Scene change, Vehicle detection
Videobasert bevegelsesdeteksjon:	Ja
Baklyskompensasjon (BLC):	Ja
Highlight Compensation (HLC):	Ja
Vinningskontrolltype (gain):	Automatisk
Dynamisk omfang:	132 dB
Tåkesikker:	Ja
Bildetekst overlegg:	Ja
Alert varslingstype:	E-mail
Nærmeste fokuseringsavstand:	0.7 m
Avstandsidentifikasjon:	2.9 m
Avstandsdeteksjon:	29 m
Observere avstand:	11.6 m
Gjenkjenne avstand:	5.8 m
Bithastighetsområde:	16 - 128 Kbit/s
Digest-autentisering:	Ja
