FEATURES/BENEFITS:
ELECTRICAL: APPLICATION TOOLS:
PHYSICAL: STANDARDS & SPECIFICATIONS:
WIRE RANGE & COMBINATIONS:
MIN. 2 #18
MAX. 4 #14 w/1 #18
MIN. 1 #18 w/1 #20
MAX. 2 #14
MIN. 2 #22
MAX. 3 #16
MIN. 2 #22 Str.
MAX. 2 #16
WIRE RANGE:
≤ #16 AWG: 1/2" (13 mm)
All Others: 7/16" (11 mm)
Solid: 1/4" (6 mm)
Str: 5/16" (8 mm)
≤ #16 AWG: 1/2" (13 mm)
All Others: 3/8" (9.5 mm)
≤ #16 AWG: 3/8" (9.5 mm)
All Others: 5/16" (8 mm)
≤ #16 AWG: 7/16" (11 mm)
All Others: 3/8" (9.5 mm)
MIN. 2 #14
MAX. 4 #12
71B
®
(GRAY)
MODEL
72B
®
(BLUE) 76B
®
(RED)74B
®
(YELLOW)73B
®
(ORANGE)
HOUSING: POLYPROPYLENE (UL 94V-2 FLAME RATED)
INSERT: STEEL
PLATING: ZINC
UL LISTED: UL 486C
CSA CERTIFIED: C22.2 NO. 188
RoHS COMPLIANT
- WIDE WIRE RANGE ENABLES USE ON VARIETY OF APPLICATIONS
- FIXED, SQUARE-WIRE SPRING CREATES ITS OWN THREADS
- MAINTAINS A SECURE CONNECTION THAT WILL NOT RELAX OVER TIME
- POSITIVE-GRIP SHELL DESIGN PROVIDES FAST, EASY INSTALLATION
- PRE-TWISTING OF WIRES IS NOT REQUIRED
- REUSEABLE FOR EASY CIRCUIT CHANGES AND ADDITIONS
COMBINATIONS:
- Listed as a
Pressure
-
Type wire
300V MAX:
1 #14
1 or 2 #16
300V MAX:
1 #14 Str.
1 #16 Str.
600V MAX:*
1 or 2 #14
1 #14 w/1 or 2 #18
600V MAX:*
1 to 3 #12
1 to 4 #14
WIRE-NUT
®
WIRE CONNECTORS
VOLTAGE: 71B
®
/ 72B
®
300 VOLTS MAX.
73B
®
/ 74B
®
/ 76B
®
600 VOLTS MAX.*
(* 1,000 VOLTS MAX. SIGNS & FIXTURES)
- ACAM (AUTOMATIC CONNECTOR APPLICATION MACHINE)
- WIRE-NUT
®
Wire Connector Sockets: (71B30-903
®
& 72B
®
), (73B30-904
®
),
30-906 (74B
®
& 76B
®
), (73BH-632
®
, 74B
®
& 76B
®
), (73B30-902
®
, 74B
®
& 76B
®
)
WIRE
STRIP LENGTH
600V MAX:*
1 or 2 #10
1 to 4 #12
MODELS
71B
®
, 72B
®
, 73B
®
, 74B
®
& 76B
®
of US and global
Made in U.S.A.
DIMENSIONS:
MODEL INCHES mm INCHES mm
71B
®
0.33 8 0.58 15
72B
®
0.39 10 0.70 18
73B
®
0.44 11 0.86 22
74B
®
0.55 14 0.95 24
76B
®
0.59 15 1.06 27
ORDERING INFO:
30-071 30-072 30-073 30-074 30-076100/Box 100/Box 100/Box 100/Box 100/Box
30-171 1,000/Carton 1,000/Carton 300/Jar 175/Jar 150/Jar30-172 30-073J 30-074J 30-076J
30-271 25,000/Keg 10,000/Keg 1,000/Carton 1,000/Carton 1,000/Carton30-272 30-173 30-174 30-176
30-871 150,000/Barrel 85,000/Barrel 500/Bag 500/Bag 250/Bag30-872 30-273 30-274 30-276
30-673 10,000/Keg 10,000/Keg 15,000/Barrel30-674 30-876
30-873 50,000/Barrel 35,000/Barrel30-874
FACTORY CONTACT: NOTES:
74B
®
(YELLOW)
76B
®
(RED)
BA
CATALOG
NUMBERS
71B
®
(GRAY)
72B
®
(BLUE)
73B
®
(ORANGE)
IDEAL INDUSTRIES, INC.
BECKER PLACE
SYCAMORE, IL 60178
PHONE: (815) 895-5181
(800) 435-0705 in USA
Pressure
Type wire
connector for use on
the following solid
and/or stranded
Cu/Cu wire
combinations.
- Consult IDEAL for
a complete list of all
UL Listed wire
combinations.
1 #18 Str.
1 #16 w/1 #18
2 #18 w/1 #20
2 or 3 #18
2 to 4 #20
4 #20 w/1 #22
2 #22 Str.
3 or 4 #22
5 #22 Sol.
1 #14 w/1 #16
1 #14 w/1 or 2 #18
2 or 3 #16
2 #16 w/1 #18
1 #18 str.
2 to 4 #18
3 to 5 #20
4 #20 w/1 #22
2 #22
1 #16 Str.
1 #14 w/1 #16
1 #16 w/1 or 2 #18
2 #16
2 #16 w/1 #18
1 #18 Str.
1 #18 w/2 to 4 #20
1 #18 w3 to 4 #22
2 to 4 #18
2 to 5 #16
3 to 6 #20
2 to 5 #18
1 #10 w/1 #12
2 #12 w/1 or 2 #18
2 #12 w/1 or 2 #14
2 #14 w/1 to 3 #18
1 #10 w/1 or 2 #14
1 #12 w/1 to 3 #14
2 to 5 #14
4 to 6 #16
1 #16 w/4 #18
1 #14 w/3 or 4 #18
2 #14 w/2 to 4 #16
2 #12 w/1 to 3 #14
1 #10 w/1 to 3 #14
1 #10 w/1 or 2 #12
2 #10 w/1 #14
Ø A
