DA-TM1100 INSTALLATION MANUAL

This manual is intended for users of the DA-TM1100 wall mounting

bracket. It includes instructions for mounting the DA-TM1100 wall

mounting bracket to a wall.

• This bracket is intended to be used with a specic

model of camera. Do not use it with other models of

cameras except for those approved by the dealer or

distributor.

• This installation should be performed by a qualied

service personnel in conformance to all local codes.

• You may need to reinforce the wall. If the wall is not

strong enough to support the camera, the camera

may fall.

• Do not use this product for other purposes.

Mounting

Mount the bracket to the wall as follows:

Insert cables from external devices, network and

power adapter to the sponge and bracket.

Mount bracket to the wall by using the provided

anchors and screws.

Bracket

Wall Hole

Connect your camera to the bracket as follows:

Screw the camera body onto bracket.

Safety wire

Bracket

Camera

body

Safety wire

Bracket

Camera

body

Produkspesifikasjoner

Merke:	IDIS
Kategori:	Ikke kategorisert
Modell:	DA-TM1100
Produkttype:	Monteringsplate
Vekt:	380 g
Bredde:	155 mm
Dybde:	155 mm
Høyde:	64.4 mm
Kompatibilitet:	DC-Y1514, DC-Y1514W, DC-Y3C14WRX, DC-Y8C13RX, DC-Y8C13WRX
Produktfarge:	Hvit
Antall medfølgende produkter:	1 stykker
