Side 1/3
BHE Series
Articulated Arms
INSTRUCTIONS
BHE-107
Two-Section Articulated Arm
BHE-117
Two-Section Double Articulat
BHE-118
Three-Section Articulated Arm
Introduction
Thank you for choosing the Impact BHE Series Articulated Arm. Often used in conju
clamp, articulated arms can mount a camera, small light xture, or light modier on
clamp can t around. The arms will also t into any baby receiver. Applicable whet
or in the studio, an articulated arm is versatile, extendable, and secure, with lockin
components.
With a camera bracket (Impact BHE-104, sold separately) on the arm, you can moun
mirrorless, or DSLR camera on anything from a riser to a bicycle to capture unique
view. Often used for time lapse photos, articulated arms are also great for action an
Made from durable and lightweight aluminum, all Impact BHE Series Articulated Ar
spigots. Each single articulated arm has either a 1/4 -20 or a 3/8 threaded socket.
articulated arm has a 3/8 threaded socket on one end and a hexagonal double anc
end. This gives the arm added strength in a super clamp. You can adjust the angle a
section of the arms and tighten both at once with a single locking knob.
Note: Always check weight limits and load capacity before attaching to location sit
Maximum leng
23.50 (59.69 c
23.63 (60.02 c
32.75 (83.19 cm
33.75 (85.73 c
Maximum load capacity
3.3 lb. (1.50 kg)
11 lb. (4.99 kg)
2.2 lb. (1.00 kg)
10 lb. (4.54 kg)
Arm type
Single
Double
Single
Double
Model
BHE-107
BHE-117
BHE-118
BHE-119
Two-section
arms
Three-section
arms
One-Year Limited Warranty
This IMPACT product is warranted to the orig inal purchaser to be free from def ects
in materials and workmanship under normal consumer use for a period of one (1) year
from the original purchase date or thirty (30) days after replacement, whichever
occurs later. The warranty providers responsibility with respect to t his limited
warranty shall be limited solely to repair or replacement, at the provider’s discretion,
of any product that fails during normal use of this product in its intended manner and
in its intended environment. Inoperabilit y of the product or part(s) shall be determined
by the warranty provider. If the product has been discontinued, the warranty provider
reserves the right to replace it with a model of equivalent quality and function.
This warranty does not cover damage or defect caused by misuse, neglect , accident,
alteration, abuse, improper installation or maintenance. E XCEPT AS PROVIDED
HE REIN, THE WARR ANT Y PROVIDE R MAKES NEIT HER ANY E XP RESS
WAR RANTIES NOR ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED
TO ANY IMPLIED WARRANT Y OF MERCHANTABILIT Y OR FITNES S FOR A
PAR TICULAR PURPOSE. This warranty provides you with specic legal rights, and
you may also have additional rights that vary from st ate to state.
To obtain warranty coverage, contact the Impact Customer Service Department to
obtain a return merchandise authorization (“RMA”) number, and return the defective
product to Impact along with the RMA number and proof of purchase. Shipment of
the defective product is at the purchaser’s own risk and expense.
For more information or to arrange service, visit w ww.impactstudiolighting.com or
call Customer Service at 212-594-235 3.
Product warran ty provided by the Gradus Group.
www.gradusgroup.com
IMPACT is a registered trademark of the Gradus Group.
© 2014 Gradus Group LLC. All Rights Reserved.
GG2
