C-SCS-RH
CC-106R/T
Super Clamp with
Ratchet Handle / T-Handle
INSTRUCTIONS
2
Thank you for choosing Impact.
clamping widths of 0.5 to 2.1 inches. The clamps hold up to
33 pounds of gear, and they feature a hex snap-in receiver that
prevents slipping or turning once your gear is attached. The
ratchet handle design is perfect for using the super clamp in
tight spaces, and it allows you to operate the jaws even when
the handle can’t rotate 360 degrees. The CC-106T’s T-handle
design is low prole and allows you to place the clamp close to
walls. The super clamps are made to securely clamp onto tubes
like light stands, poles, and trusses. An included wedge can be
added for clamping to at surfaces like tables, shelves, or doors.
Please read and follow
these instructions, and
keep this manual in a safe
place.
Clean the unit with only a
soft, dry cloth.
Make sure everything is
secure before proceeding.
Make sure that this
product is intact and that
there are no missing parts.
Do not exceed the
maximum load capacity.
All images are for
illustrative purposes only.
3
1. Locking knob
2. Wedge
3. Hex receiver
4. 1/4-20 threaded receiver
5. M5 threaded receivers
6. Hex safety lock
7. Bottom jaw
8. Top jaw
9. Ratchet handle
1. Locking knob
2. Wedge
3. Hex receiver
4. 1/4-20 threaded receiver
5. M5 threaded receivers
6. Hex safety lock
7. Bottom jaw
8. Top jaw
9. T-handle
1 12 23 34 4
5
5
6
6
7
7
8
8
9
9
C-SCS-RH / CC-106R CC-106T
