KICKER MARINE SPEAKERS

KM4

KM65

KM8

Owner’s Manual | English

Manual del Propietario | Español

ALTAVOZ COAX KM

Benutzerhandbuch | Deutsch

KM KOAX-SYSTEM

Manuel d’utilisation | Français

HAUT-PARLEURS COAXIAUX KM

Coaxial Speakers

2014 KM Coax Rev d.indd 12014 KM Coax Rev d.indd 1 11/22/2013 11:44:25 AM11/22/2013 11:44:25 AM

The KICKER KM coaxial speakers are speciﬁ cally designed for mounting in free-air applications. The

speakers do not require a sealed enclosure for optimum performance. It is important to isolate the sound

coming off the front of the driver from the sound radiating from the back of the driver. This isolation is

usually accomplished by using the driver in a factory speaker location, or in a location with a semi-isolated

rear chamber.

SPECIFICATIONS

Authorized KICKER Dealer:

Purchase Date:

Speaker Model Number:

LOCATION

The sound produced by the KM coaxials is directional. Find the best location for stereophonic sound. If

necessary, add more KM coaxial speakers to the system to help distribute and balance the sound-stage.

After determining the best mounting locations, carefully check the areas where the mounting hardware will

be placed.

Model: KM4 KM65 KM8

Woofer [in, mm] 4, 100 6-1/2, 160 8, 200

Tweeter [in,mm] 1/2, 13 3/4, 20 1, 25

Rated Impedance [Ω] 2, 4 2, 4 4

Peak Power Handling [ Watts] 150 195 300

Continuous Power Handling [Watts RMS] 50 65 150

Sensitivity [1W, 1m] 89 90 92

Frequency Response [Hz] 60-20k 35-21k 30-21k

Mounting Hole Diameter [in, mm] 3-13/16, 97 5-1/8, 130 6-11/16, 170

Mounting Depth [in, mm] 1-7/8, 48 2-7/8, 72 3-1/4, 82

Grilles Yes Yes Yes

Tweeter Magnet Material Neodymium Neodymium Neodymium

Tweeter Dome Material PEI (polyether imide) Titanium Titanium

Tweeter Design Balanced Dome Dome Dome

Woofer Cone Material Polypropylene Polypropylene Polypropylene

Woofer Surround Material Santoprene Santoprene Santoprene

KM Coaxial Speakers

Owner’s Manual

Pro Tip: You are one KXM Ampliﬁ er and a few cables away from a complete, high-quality system with

rock-solid bottom end as only available from KICKER! Please ask your dealer about KICKER KXM ampliﬁ er

upgrades.

2014 KM Coax Rev d.indd 22014 KM Coax Rev d.indd 2 11/22/2013 11:44:33 AM11/22/2013 11:44:33 AM

Mount the speaker and

grille right side-up to take

advantage of the coaxial

system’s integrated

moisture draining system.

Loops for mounting with Zip Ties

Locking Terminal Cover

Wire Divider

Possible locations for KM

Coaxial Speaker Mounting

Mounted in the Bow

Mounted

Mid-Ship

Stern

Mounted

INSTALLATION

Mounting: Make sure the stainless steel mounting screws and U-type speed clips will not puncture the

fuel cell, wiring, or interfere with any mechanical parts on the underside of the mounting surface. Pre-drill

the mounting screw holes using a 7/64” (2.5mm) bit, and attach the KM coaxial speakers to the boat

by fastening the supplied stainless steel coarse-threaded screws to the boat’s structure. If applicable,

use the enclosed stainless steel U-type speed clips. If the supplied hardware is not applicable to your

installation, some other means of securely attaching the speakers to the boat must be used.

Wiring: Carefully place the speaker wire in a location that is clear of standing water and moving

components of the boat. For reference, the Blue wire is Positive and the Grey wire is Negative. The

locking terminal cover with water resistant gasket is removable for wiring installation; it helps prevent

terminal corrosion and electrical shorting. Connect the gold-plated male quick-disconnect on the end of

the 18 inch (46cm) speaker wire leads coming out of the sealed speaker basket to the wires from your

ampliﬁ er or source unit. Place the connected wires into the locking terminal, making sure the divider

separates the blue and silver wire quick disconnects, and snap the locking terminal cover into place.

Connect the other end of the wire to your ampliﬁ er in accordance with its owner’s manual. Mount the

locking terminal cover in a location free and clear of standing water by utilizing the supplied zip ties

through the integrated loops in the locking terminal cover.

2014 KM Coax Rev d.indd 32014 KM Coax Rev d.indd 3 11/22/2013 11:44:33 AM11/22/2013 11:44:33 AM

Produkspesifikasjoner

Merke:	Kicker
Kategori:	Høyttaler
Modell:	KM60
Impedans:	4 Ω
Toppeffekt:	150 W
Diskanthøyttaler:	Ja
Nominell effekt:	50 W
Forsterker inkludert:	Nei
Separate komponenter:	Nei
Subwoofer inkludert:	Nei
Høyttaler type:	2-veis
Frekvensrekkevidde:	35 - 21000 Hz
Basshøyttalerens diameter:	160 mm
Diskant diameter:	13 mm
Sensitivitet/følsomhet:	90 dB
Innbygningsdybde:	62 mm
Diameter for monteringshull:	132 mm
