Side 1/28
USER INSTRUCTION MANUAL
SELF-RETRACTING DEVICES
THESE INSTRUCTIONS APPLY TO THE FOLLOWING MODELS:
UFS310010, UFS310020, UFS310030, UFS310050, UFS310100, UFS310130, UFS310150,
UFS350011, UFS350025, UFS310060R, UFS310100R, UFS480020, UFS480030, UFS480050,
UFS310018L, UFS310025L, UFS310050L, UFS310080L, UFS316106L, UFS314006L, UFS310206L, UFS319006L,
UFS310206LD, UFS316106LD, UFS314006LD, UFS319006LD, UFS359002, UFS359002D, UFS351102, UFS351102D,
UFS350002, UFS350002D, UFS354002, UFS354002D, UFS356002, UFS356002D, UFS359506, UFS359506D,
UFS389006D, UFC409151 (Twin SRL Connector)
2
This is the manufacturer’s instruction manual drafted with an intention to meet the requirements of ANSI Z359.14 and OSHA 1926. As per OSHA
this manual should be used as a part of an employee training program.
WARNING
The products enumerated in this Instruction Manual are a part of a personal protective, work support or rescue system. It is important that the
user reads and follows the manufacturer’s instructions for each component of the system. This manual contains information which is important
to your safety and should be kept in a safe place for future reference as needed. The instructions provided in this manual are meant for the use
of this equipment and should be read thoroughly and understood by the user before the equipment is used. Manufacturer’s instructions must
be properly followed for the correct use and maintenance of this equipment. Please contact KStrong for any questions regarding use of this
equipment.
1. TRAINING
In order to ensure that the user is familiar with the instructions provided in this manual, it becomes the responsibility of the user to undergo
proper training for this, and also for correct care and use of this equipment. It is also the employer’s responsibility to ensure that all users
are trained in proper use, inspection and maintenance of Fall Protection Equipment.
2. TECHNICAL SPECIFICATIONS: (All-Regular, LE, Retrieval and Micron™)
S.
No.
KStrong
Model
SRL
Series
Lifeline Material
and Size
Lifeline
Length
Weight
(lbs.)
Minimum
Breaking
Strength
Conformity
1 UFS310010
BRUTE™ -
SRL
(Cable)
Casing: Robust and durable plastic
Cable: Galvanized steel wire rope
(Ø 3/16 inch)
Metal: Steel Snap Hook
10 ft.
11.22 lbs.
±0.02 lbs.
3400 lbs. ANSI Z359.14-2014
2 UFS310020
Casing: Robust and durable plastic
Cable: Galvanized steel wire rope
(Ø 3/16 inch)
Metal: Steel Snap Hook
20 ft.
6.93 lbs.
±0.02 lbs.
3400 lbs. ANSI Z359.14-2014
3 UFS310030
Casing: Robust and durable plastic
Cable: Galvanized steel wire rope
(Ø 3/16 inch)
Metal: Steel Snap Hook
30 ft.
10.20 lbs.
±0.02 lbs.
3400 lbs. ANSI Z359.14-2014
4 UFS310050
Casing: Robust and durable plastic
Cable: Galvanized steel wire rope
(Ø 3/16 inch)
Metal: Steel Snap Hook
50 ft.
12.45 lbs.
±0.02 lbs.
3400 lbs. ANSI Z359.14-2014
5 UFS310100
Casing: Robust and durable plastic
Cable: Galvanized steel wire rope
(Ø 3/16 inch)
Metal: Steel Snap Hook
100 ft.
31.36 lbs.
±0.02 lbs.
3400 lbs. ANSI Z359.14-2014
6 UFS310130
Casing: Robust and durable plastic
Cable: Galvanized steel wire rope
(Ø 3/16 inch)
Metal: Swivel Locking Carabiner
30 ft.
10.20 lbs.
±0.02 lbs.
3400 lbs. ANSI Z359.14-2014
7 UFS310150
Casing: Robust and durable plastic
Cable: Galvanized steel wire rope
(Ø 3/16 inch)
Metal: Swivel Locking Carabiner
50 ft.
12.45 lbs.
±0.02 lbs.
3400 lbs. ANSI Z359.14-2014
8 UFS350011
BRUTE™ -
SRL (Web)
Casing: Robust and durable plastic
Textile: Polyester webbing (1 inch)
Metal: Steel Snap Hook
11 ft.
4.14 lbs.
±0.02 lbs.
4500 lbs. ANSI Z359.14-2014
9 UFS350025
Casing: Robust and durable plastic
Textile: Polyester webbing (1 inch)
Metal: Steel Snap Hook
25 ft.
7.42 lbs.
±0.11 lbs.
4500 lbs. ANSI Z359.14-2014
