Side 1/28
USER INSTRUCTION MANUAL
SELF-RETRACTING DEVICES
THESE INSTRUCTIONS APPLY TO THE FOLLOWING MODELS:
UFS310010, UFS310020, UFS310030, UFS310050, UFS310100, UFS310130, UFS310150,
UFS350011, UFS350025, UFS310060R, UFS310100R, UFS480020, UFS480030, UFS480050,
UFS310018L, UFS310025L, UFS310050L, UFS310080L, UFS316106L, UFS314006L, UFS310206L, UFS319006L,
UFS310206LD, UFS316106LD, UFS314006LD, UFS319006LD, UFS359002, UFS359002D, UFS351102, UFS351102D,
UFS350002, UFS350002D, UFS354002, UFS354002D, UFS356002, UFS356002D, UFS359506, UFS359506D,
UFS389006D, UFC409151 (Twin SRL Connector)
2
This is the manufacturer’s instruction manual drafted with an intention to meet the requirements of ANSI Z359.14 and OSHA 1926. As per OSHA
this manual should be used as a part of an employee training program.
WARNING
The products enumerated in this Instruction Manual are a part of a personal protective, work support or rescue system. It is important that the
user reads and follows the manufacturer’s instructions for each component of the system. This manual contains information which is important
to your safety and should be kept in a safe place for future reference as needed. The instructions provided in this manual are meant for the use
of this equipment and should be read thoroughly and understood by the user before the equipment is used. Manufacturer’s instructions must
be properly followed for the correct use and maintenance of this equipment. Please contact KStrong for any questions regarding use of this
equipment.
1. TRAINING
In order to ensure that the user is familiar with the instructions provided in this manual, it becomes the responsibility of the user to undergo
proper training for this, and also for correct care and use of this equipment. It is also the employer’s responsibility to ensure that all users
are trained in proper use, inspection and maintenance of Fall Protection Equipment.
2. TECHNICAL SPECIFICATIONS: (All-Regular, LE, Retrieval and Micron™)
S.
No.
KStrong
Model
SRL
Series
Lifeline Material
and Size
Lifeline
Length
Weight
(lbs.)
Minimum
Breaking
Strength
Conformity
1 UFS310010
BRUTE™ -
SRL
(Cable)
Casing: Robust and durable plastic
Cable: Galvanized steel wire rope
(Ø 3/16 inch)
Metal: Steel Snap Hook
10 ft.
11.22 lbs.
±0.02 lbs.
3400 lbs. ANSI Z359.14-2014
2 UFS310020
Casing: Robust and durable plastic
Cable: Galvanized steel wire rope
(Ø 3/16 inch)
Metal: Steel Snap Hook
20 ft.
6.93 lbs.
±0.02 lbs.
3400 lbs. ANSI Z359.14-2014
3 UFS310030
Casing: Robust and durable plastic
Cable: Galvanized steel wire rope
(Ø 3/16 inch)
Metal: Steel Snap Hook
30 ft.
10.20 lbs.
±0.02 lbs.
3400 lbs. ANSI Z359.14-2014
4 UFS310050
Casing: Robust and durable plastic
Cable: Galvanized steel wire rope
(Ø 3/16 inch)
Metal: Steel Snap Hook
50 ft.
12.45 lbs.
±0.02 lbs.
3400 lbs. ANSI Z359.14-2014
5 UFS310100
Casing: Robust and durable plastic
Cable: Galvanized steel wire rope
(Ø 3/16 inch)
Metal: Steel Snap Hook
100 ft.
31.36 lbs.
±0.02 lbs.
3400 lbs. ANSI Z359.14-2014
6 UFS310130
Casing: Robust and durable plastic
Cable: Galvanized steel wire rope
(Ø 3/16 inch)
Metal: Swivel Locking Carabiner
30 ft.
10.20 lbs.
±0.02 lbs.
3400 lbs. ANSI Z359.14-2014
7 UFS310150
Casing: Robust and durable plastic
Cable: Galvanized steel wire rope
(Ø 3/16 inch)
Metal: Swivel Locking Carabiner
50 ft.
12.45 lbs.
±0.02 lbs.
3400 lbs. ANSI Z359.14-2014
8 UFS350011
BRUTE™ -
SRL (Web)
Casing: Robust and durable plastic
Textile: Polyester webbing (1 inch)
Metal: Steel Snap Hook
11 ft.
4.14 lbs.
±0.02 lbs.
4500 lbs. ANSI Z359.14-2014
9 UFS350025
Casing: Robust and durable plastic
Textile: Polyester webbing (1 inch)
Metal: Steel Snap Hook
25 ft.
7.42 lbs.
±0.11 lbs.
4500 lbs. ANSI Z359.14-2014
3
S.
No.
KStrong
Model
SRL
Series
Lifeline Material
and Size
Lifeline
Length
Weight
(lbs.)
Minimum
Breaking
Strength
Conformity
10 UFS310060R
BRUTE™ -
SRL-R
Casing: Robust and durable plastic
Cable: Galvanized steel wire rope
(Ø 3/16 inch)
Metal: Steel Snap Hook
60 ft.
17.28 lbs.
±0.22 lbs.
3400 lbs. ANSI Z359.14-2014
11 UFS310100R
Casing: Robust and durable plastic
Cable: Galvanized steel wire rope
(Ø 3/16 inch)
Metal: Steel Snap Hook
100 ft.
33.41 lbs.
±0.22 lbs.
3400 lbs. ANSI Z359.14-2014
12 UFS310018L
BRUTE™
SRL-LE
SERIES
Casing: Robust and durable plastic
Cable: Galvanized steel wire rope
(Ø 7/32 inch)
Metal: Steel Snap Hook
18 ft.
7.6 lbs.
±0.02 lbs.
3400 lbs. ANSI Z359.14-2014
13 UFS310025L
Casing: Robust and durable plastic
Cable: Galvanized steel wire rope
(Ø 7/32 inch)
Metal: Steel Snap Hook
25 ft.
9.22 lbs.
± 0.02 lbs.
3400 lbs. ANSI Z359.14-2014
14 UFS310050L
Casing: Robust and durable plastic
Cable: Galvanized steel wire rope
(Ø 7/32 inch)
Metal: Steel Snap Hook
50 ft.
12.45 lbs.
± 0.02 lbs.
3400 lbs. ANSI Z359.14-2014
15 UFS310080L
Casing: Robust and durable plastic
Cable: Galvanized steel wire rope
(Ø 7/32 inch)
Metal: Steel Snap Hook
80 ft.
31.86 lbs.
± 0.22
lbs.
3400 lbs. ANSI Z359.14-2014
16 UFS480020L
Casing: Robust Aluminum Alloy
Cable: Galvanised steel wire rope (Ø7/32 inch)
Metal: Steel hook
20 ft.
10.94 lbs
± 0.02 lbs
3800 lbs. ANSI Z359.14-2014
17 UFS480025L
Casing: Robust Aluminum Alloy
Cable: Galvanised steel wire rope (Ø7/32 inch)
Metal: Steel hook
25 ft.
11.51 lbs
± 0.02 lbs
3400 lbs. ANSI Z359.14-2014
18 UFS480050L
Casing: Robust Aluminum Alloy
Cable: Galvanised steel wire rope (Ø7/32 inch)
Metal: Steel hook
50 ft.
16.36 lbs
± 0.02 lbs
3400 lbs. ANSI Z359.14-2014
19 UFS310206L
BRUTE™
BACKER-
LE
SERIES
Casing: Polymer Casing
Cable: Galvanized steel wire rope
(Ø 3/16 inch)
Metal: Steel Snap Hook
8 ft.
3.65 lbs.
±0.02 lbs.
3400 lbs. ANSI Z359.14-2014
20 UFS314006L
Casing: Polymer Casing
Cable: Galvanized steel wire rope
(Ø 3/16 inch)
Metal: Steel Swivel Rebar Hook
8 ft.
4.17 lbs.
±0.02 lbs.
3400 lbs. ANSI Z359.14-2014
21 UFS316106L
Casing: Polymer Casing
Cable: Galvanized steel wire rope
(Ø 3/16 inch)
Metal: Aluminum Swivel Rebar Hook
8 ft.
3.77 lbs.
± 0.02 lbs.
3400 lbs. ANSI Z359.14-2014
22 UFS319006L
Casing: Polymer Casing
Cable: Galvanized steel wire rope
(Ø 3/16 inch)
Metal: Steel Tie-Back Hook
8 ft.
4.08 lbs.
±0.02 lbs.
3600 lbs. ANSI Z359.14-2014
23 UFS310206LD
Casing: Polymer Casing
Cable: Galvanized steel wire rope
(Ø 3/16 inch)
Metal: Steel Snap Hooks
Dual 8 ft.
8.25 lbs.
±0.02 lbs.
3400 lbs. ANSI Z359.14-2014
24 UFS314006LD
Casing: Polymer Casing
Cable: Galvanized steel wire rope
(Ø 3/16 inch)
Metal: Steel Swivel Rebar Hooks
Dual 8 ft.
8.77 lbs.
±0.02 lbs.
3400 lbs. ANSI Z359.14-2014
