Side 1/7
Outdoor temperature sensor
World Time Center
• Remote transmission of outdoor temperature via 433MHz to base World Time Center.
• LCD display showing current outdoor temperature in Fahrenheit (ºF)
• Shower proof casing
• Wall mounting case
Introduction
Getting started
Congratulations on purchasing this state-of-the-art World Time Center as an example of superior design and
engineering. Providing radio controlled time, indoor temperature and humidity displays, outdoor temperature, this unit will
never keep you guessing on time, date or current and future weather conditions. Operation of this product is simple and
straightforward. By reading this operating manual, the user will however receive a better understanding of the WorldTime
Center together with the optimum benefit of all its features.
Remove all parts from the packaging and place onto a table in front of you. Ensure that the following parts are included:
1. World Time Center (main unit)
2. Outdoor temperature sensor
3. Instruction manual
World Time Center
If any one of the above mentioned parts is missing please contact your supplier.
Hanging Hole
LCD display
Holder
Outdoor temperature sensor
Battery cover
LCD2
LCD3
LCD1
SET-Key
WORLDTIME-Key
TIMEZONE-Ke
y
+ -Key
HYGRO-Key
Please follow all further explanations and descriptions in this manual in order to ensure that your World Time
Center and Outdoor temperature sensor work correctly.
Important Note:
For all users wanting to get additional informations on the function of the World Time Center there is an
alphabetically sorted subject index at the end of this manual offering a number of technical and functional
explanations. For use and operation of this product however the knowledge of this index is not necessary.
Putting into Operation
Basic Setup
Features
World Time Center
• 4 digits showing Hour and Minute in the main display
• WWVB time signal radio-controlled clock with manual time display
• 12/24 hour display
• Time zone selectable
• World time display with specific place represented by 3 sucessive characters
• Calendar display
• Display of weekday (8 languages to choose from)
• Display of current indoor temperature
• Display of current indoor relative humidity
• Three weather icons for weather forecasting
• Weather tendency indicators
• °C or °F temperature display selectable
• LCD contrast changeable to 8 different tones
• Low battery indicator
• Wall Mounting
Battery
Compartment
Battery Cover
1. Open the battery cover of the World Time Center and - checking the correct polarities –
insert 3 x AA, IEC LR6 1.5V batteries into the battery compartment as indicated above and replace the cover.
Battery cover
Battery
compartment
2. Unscrew the screw on the back of the Outdoor temperature sensor compartment and remove the cover.
3. Insert the 2 x AAA, IEC LR3, 1.5V batteries observing correct polarity.
4. Replace battery cover on unit and seal by re-screwing
5. When replacing the battery covers, ensure that the batteries do not spring free from the contacts.
6. Your World Time Center and Outdoor temperature sensor are now operational.
Reset
Produkspesifikasjoner
| Merke: | La Crosse Technology |
| Kategori: | Klokke |
| Modell: | WS-7098U |
