Side 1/4

LevelOne

User Manual

POT-xxxx Series

PoE Pepeater over 2- M/S wire

1. Introductions

The POT system, one master & one slave units, provide a long reach Ethernet extension with remote -

P -o -E -ower ver thernet (PoE) capability over a 2 wire line. Connection with a Class 0 PD , the distance device

of two-wire 24AWG cables can be up to 00 meters when using a 43 8Watt high power PoE Switch,

FSW- . 0513/0543 Users may select a fixed data rate for different copper line ranging. The maximum data rate

can be up to 0 Mbps full duplex for 2 6 - wire line.

The POT master unit is powered by the local , and transmits both the data and power to PoE Ethernet network

the remote slave unit over 2 The remote unit regenerates the power and provides the PoE - wire cable.

capability to power up the remote PD device up to High Power 15 watts when connect atting to 48W Switch,

FSW- - 0513. The POT M/S supports the indoor & outdoor models with wall mount feature.

Equipped with thedip switches, 2-wire line speed can be configured to meet different line gauges and

distances LAN . A POT pair offers a cost effective solution for remote power applications such as LAN- -to

connectivity, Video Streaming, FTTB, and MDU/MTU over single twisted line.

IP-66

POT-1110 is IP66 is IP66 compliant meaning it is weatherproof from snow, rain, typhoon, desert heat, etc. this -

PoE Repeater is up to the challenge for deployment in any harsh weather condition.

Produkspesifikasjoner

Merke:	LevelOne
Kategori:	wifi-repeterer
Modell:	POT-0100
Bredde:	90 mm
Dybde:	120 mm
Høyde:	28 mm
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Opprinnelsesland:	Taiwan
Pakkevekt:	540 g
Strømforbruk (maks.):	15 W
Sertifisering:	FCC Rules Part 15\nCE
Kablingsteknologi:	10/100Base-T(X)
Nettverksstandard:	IEEE 802.3, IEEE 802.3u
Utgangsstrøm:	57 V
Auto MDIX IEEE:	Ja
Produktfarge:	Sort
Pakkedybde:	235 mm
Pakkehøyde:	80 mm
Pakkebredde:	148 mm
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	0 - 50 °C
Harmonisert system (HS)-kode:	85176990
Modell/Type:	Gjentaker
Relativ luftfuktighet under drift (H-H):	5 - 95
Overføringshastighet (Mbps):	60 Mbit/s
Maksimal overføring avstand:	400 m
Tosidig system:	Full, Half
Antall RJ11-porter:	1
