Double the range of RS-232 data communications

in heavy industrial areas.

Rugged IP30-rated metal case

for panel mounting

Industrial Opto-Isolated RS-232 Repeater

ICD201A

This heavy-duty Industrial Opto-Isolated RS-232 Repeater

doubles the maximum allowable distance permitted under the

RS-232 specification for longer serial transmissions.

Encased in an IP30-rated enclosure, the repeater's been put

through some of the most exacting tests in the industry. The

high-grade repeater meets the requirements of two standards

that make it suitable for electrical substation installations—IEC

61850-3 and IEEE 1613—specifications that are more stringent

than NEMA TS1/TS2 requirements for transportation

applications.

Overview

• A heavy-duty, industrial-strength repeater.

• Doubles the allowable range of RS-232 transmissions up to

100 feet (30.4 m).

• Rugged, IP30-rated metal case for panel mounting.

• Tolerates temperatures ranging from -40 to +176º F

(-40 to +80º C).

• Designed to withstand both shock and vibration.

• Boasts 2-kV triple isolation for safeguarding data and

equipment.

• Data rates up to 115.2 kbps.

Page 2

724-746-5500 | blackbox.com

Industrial Opto-Isolated RS-232 Repeater

Specifications

Approvals — IEC 61850-3, IEEE 1613, FCC, CE, RoHS

Data Rates (Maximum) —115.2 kbps

Distance — 100 ft. (30.4 m); longer distances may be possible depending on the cable’s capacitance

Enclosure— IP30-rated metal, panelmount

Insulation Resistance — ≥ 500 M ohms @ 500 VDC

Isolation — 2 kV RMS, 1 minute

Maximum Torque — 5 kg/cm

MTBF — 194,712 hours;

Calculation method: parts count reliability prediction

Pitch — 5.08 mm

Wire Size Accepted — 28 to 12 AWG

CE Approval — Yes

RoHS — Yes

Connectors — DCE: (1) DB9 F; DTE: (1) DB9 M

Indicators — LEDs: (1) Power, (1) TD (transmit data) and (1) RD (receive data) on both the DCE and DTE ports

Operating Environment — Temperature: -40 to +176º F (-40 to +80º C);

Humidity: 0 to 95%, noncondensing

Power — From an external power supply (not included);

Input: 10–48 VDC (56 VDC maximum) on 2-position terminal block (removable);

Consumption: 0.6 W typical (1.5 W with termination)

Size — 1.3"H x 3.7"W x 5.2"D (3.3 x 9.4 x 13.2 cm)

Weight — 0.5 lb. (0.2 kg)

ICD201A

Produkspesifikasjoner

Merke:	Black Box
Kategori:	wifi-repeterer
Modell:	ICD201A
Vekt:	200 g
LED-indikatorer:	Ja
Sertifisering:	RoHS
Inngangsspenning:	10 - 48 V
Vertsgrensesnitt:	RS-232
Dimensjoner (B x D x H):	94 x 132 x 33 mm
Isolasjon:	2 kV
Produktfarge:	Black, Blue
Montering:	Vegg/DIN
