Side 1/6
Installer: Manual must remain
with owner/operator.
Record information:
Model:
7000 Apple Tree Avenue
Bergen, NY 14416
ph: 1-800-543-2550
fax: 1-585-494-1839
www.LibertyPumps.com
Keep this manual handy for future reference.
For replacement manual, visit LibertyPumps.com,
or contact Liberty Pumps at 1-800-543-2550.
Retain dated sales receipt for warranty.
Serial:
Mfg Date:
Install Date:
Installation Manual
2138000H
Copyright © Liberty Pumps, Inc. 2023
All rights reserved.
ALM-Series Indoor Alarms
Features
• NEMA 1 enclosure - rated for indoor use only
• Automatic alarm and alarm silence reset
• 360° red alarm indicator beacon
• 4 ft (1.2 m) power cord
• 9V battery back-up with low battery indicator
• Multiple level sensing options available
• Auxiliary dry contacts for triggering external alarm
• Pre-installed connector on puddle sensor for ease of installation
• Internet connectivity available with NightEye
®
enabled devices
Models
Standard
•ALM-P1
•ALM-2
• ALM-2-1
•ALM-PK
NightEye
®
Wireless Enabled
•ALM-P1-EYE
• ALM-2-EYE
• ALM-2-1-EYE
• ALM-PK-EYE
NightEye® enabled version shown
2 | EN Copyright © Liberty Pumps, Inc. 2023
All rights reserved. 2138000H
Contents
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 | EN
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 | EN
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 | EN
Operation and Maintenance . . . . . . . . . . . . . . . . . . . . 4 | EN
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 | EN
Safety Guidelines
Safety Precautions
Always disconnect power before installing or servicing this
product. Qualified personnel must install and service this
product according to applicable electrical and plumbing
codes.
Always wear dielectric rubber boots and other applicable
Personal Protective Equipment (PPE) when water is on the
floor and an energized pump or alarm system must be
serviced as submerged electrical connections can energize the
water. Do not enter the water if the water level is higher than
the PPE protection or if the PPE is not watertight.
Do not install this alarm system outdoors. The system is rated
for indoor use only.
All electrical and safety practices shall be in accordance with
the National Electrical Code
®
, the Occupational Safety and
Health Administration, or applicable local codes and
ordinances.
Do not use this product with or near flammable or explosive
fluids such as gasoline, fuel oil, kerosene, etc.
This product is not to be installed in locations classified as
hazardous in accordance with the National Electric Code
®
,
ANSI/NFPA 70.
Alarm float adapters cannot be used with puddle sensors.
Do not cut the connector off a puddle sensor and wire it to the
float adapter. The sensor uses three wires for communication
and the float adapter has only two terminal blocks.
General Information
Each Liberty Pumps alarm system is tested individually in the
factory to ensure proper performance and operation. Closely
following these instructions will eliminate potential operating
problems, providing years of trouble-free service.
This high water level alarm system is designed for applications such
as monitoring sump pump basins, sewage pump basins, and water
powered back-up pumps. The alarm system comes standard with a
9V battery backup to enable continuous water level monitoring,
even when the power is out. A built-in battery monitor alerts the
user when the 9V battery needs to be replaced. Replace product
immediately if sensor or power cable becomes damaged or
severed.
NightEye® enabled devices come equipped with wireless internet
connectivity. These devices can connect to your wireless network,
by means of an Android® or iOS® device, and send notifications
about your system in real time. This system provides peace of mind
about the status of your pump system even when you are not
home.
All of the alarms come standard with Liberty Pumps 360° red alarm
beacon powered by super-bright LEDs. In combination with the
86 dB (at 10 ft/3 m) alarm siren, the alarm is sure to alert occupants
of any high-water condition.
Each device is specifically designed for use in an indoor residential
wastewater application. The system comes with liquid level sensor
that conforms to the needs of the intended application. The sensor
types are as follows:
• Snap-on enclosed float for Sump Pump Applications:
ALM-P1, ALM-P1-EYE, SJ10A, SJ10A-EYE
• Tethered float for Sewage Pump Applications:
ALM-2, ALM-2-1, ALM-2-EYE, ALM-2-1-EYE
• Water puck for Puddle Sensing:
ALM-PK, ALM-PK-EYE
To install up to three sensors, use Liberty Pumps alarm connector
splitter (sold separately, kit #K001633). A maximum of 2 pucks can
be used on a single alarm. Acceptable configurations: 3 floats; 2
floats and 1 puck; or 1 float and 2 pucks.
This safety alert symbol is used in the manual
and on the pump to alert of potential risk for
serious injury or death.
This safety alert symbol identifies risk of
electric shock. It is accompanied with an
instruction intended to minimize potential risk
of electric shock.
This safety alert symbol identifies risk of fire.
It is accompanied with an instruction intended
to minimize potential risk of fire.
This safety alert symbol identifies risk of
serious injury or death. It is accompanied
with an instruction intended to minimize
potential risk of injury or death.
Warns of hazards which if not avoided will
result in serious injury or death.
Warns of hazards which if not avoided could
result in serious injury or death.
Warns of hazards which if not avoided could
result in minor or moderate injury.
Signals an important instruction related to the
pump. Failure to follow these instructions
could result in pump failure or property
damage.
Read every supplied manual before using
pump system. Follow all the safety instructions
in manual(s) and on the pump. Failure to do so
could result in serious injury or death.
RISK OF ELECTRIC SHOCK
RISK OF FIRE
These devices are not for use outdoors, not even when
placed in a secondary enclosure.
