M-Audio Hammer 88 Pro Bruksanvisning

M-Audio Tastatur Hammer 88 Pro

Les nedenfor 📖 manual på norsk for M-Audio Hammer 88 Pro (71 sider) i kategorien Tastatur. Denne guiden var nyttig for 2 personer og ble vurdert med 3.9 stjerner i gjennomsnitt av 1.5 brukere

Last ned PDF

Side 1/71

User Guide

English ( 2 – 63 )

Appendix

English ( 64 – 69 )

Introduction

Box Contents

Hammer 88 Pro Quickstart Guide

Music Rest User Guide (download)

USB Cable Safety & Warranty Manual

Software Download Card

Important: Visit m-audio.com to download the Hammer 88 Pro Preset Editor. The Preset

Editor gives you a visual and intuitive way to edit the various messages that Hammer 88 Pro's

controls send to your computer without having to use the hardware interface.

Support

For the latest information about this product (system requirements, compatibility information,

etc.) and product registration, visit m-audio.com.

For additional product support, visit m-audio.com/support.

Setup

Connection

To start using your Hammer 88 Pro series keyboard, you need to connect your equipment, get

your software properly configured, and then set the keyboard’s operation Mode.

To connect your Hammer 88 Pro series keyboard to your computer, use the included USB

cable. Plug the USB-B end of the cable into the keyboard and the USB-A end of the cable into

your computer (or into a USB hub connected to your computer).

Note: In addition to sending data, the USB cable powers the keyboard. If you will be

connecting your Hammer 88 Pro series keyboard to a USB hub that has other devices

connected to it, then we recommend using a powered USB hub.

Produkspesifikasjoner

Merke:	M-Audio
Kategori:	Tastatur
Modell:	Hammer 88 Pro
Innebygd skjerm:	Ja
Vekt:	18500 g
Bredde:	1422 mm
Dybde:	282 mm
Høyde:	127 mm
Strømkildetype:	USB
MIDI inn:	Ja
Forhåndsinstallert programvare:	Pro Tools \| First M-Audio Edition, MPC Beats, Ableton Live Lite, Hybrid 3.0, AIR Music’s Velvet, AIR Music’s Mini Grand, Vacuum Classic, Boom, DB-33 Tonewheel Organ
Produktfarge:	Sort
Skjermtype:	OLED
Kontrolltype:	Buttons, Rotary, Slider
Kabler inkludert:	USB
MIDI-utgang:	Ja
Videoopptaksgrensesnitt:	USB
Antall taster på MIDI-tastatur:	88 taster
Fotpedalinnput:	Ja
Antall knapper/pads:	16
Oktav-justering:	Ja
Toppbøyehjul:	Ja
