Side 1/2
Features
Comply with IEEE802.3, IEEE802.3u, IEEE802.3af/at standards
Support IEEE802.3x full-duplex flow control; support Auto MDI/MDIX
24 Ports support 48V-56VDC power to PoE powered devices
Provide 15.4W or 30W power to powered devices
Gigabit uplink RJ-45 port: 2 x 10/100/1000Mbps
250 watts PoE budget
PoE data & power transmission distance up to 100 meters
Port based VLAN for Enhanced Security
Transmission distance max up to 250 meters when VLAN is enabled
Excellent anti-thunder,anti-static and anti-interference ability
Surge protection: 2KV
Restart function helps master IC reset wholly
Built-in 250W power supply
Easy and convenient to use, plug & play, no need to configure
Galvanized housing for stable and durable working life
Overview
The SW-UF24P2GV-062 provides 24 ports 10/100Mbps IEEE802.3af/at Power over
Ethernet with a total of 250 watts of PoE budget, which is an ideal solution to fulfill the
demand of sufficient PoE power for network applications.
The SW-UF24P2GV-062 is an ideal solution for securing IP surveillance infrastructure. It
provides both 802.3af/at PoE functions along with 24 x 10/100Mbps ports featuring 15.4
watts 802.3af/30 watts 802.3at PoE in RJ-45 interfaces and extra 2-Gigabit uplink port:
10/100/1000Mbps RJ-45 to keep a cascade connection with another switch or NVR. For
instance, one 24 Channels NVR and 24 PoE IP cameras as a kit for the administrators to
centrally and efficiently manage the surveillance system in the local LAN and the remote
site via Internet.
With data and power over Ethernet from one unit, the SW-UF24P2GV-062 reduces
cabling requirements and eliminates the need for dedicated electrical outlets on the wall,
ceiling or any unreachable place. A wire that carries both data and powe can lower the
installation costs, simplify the installation effort and eliminate the need for electricians or
extension cords. Providing 24 PoE interfaces, the SW-UF24P2GV-062 is ideal for small
businesses and workgroups requiring deploying the PoE for the wireless access points,
IP-based surveillance IP phones in any places easily, efficiently and cost-effecvely.
visit our website
www.machpower.it
USER MANUAL SW-UF24P2GV-062
Front panel
1. Rack-mounting ears: Cabinets for product installation or Wall installation
2. Downlink RJ45 port: Transfer data from other IP devices to the switch
3. Gigabit Uplink RJ45 Port: Transfer data from PoE ports to other devices (NVR/Swi-
tch/ADSL)
4. VLAN Button: Turn on VLAN button: indicator on and VLAN function starts
Turn off VLAN button: indicator off and VLAN function stops
5. Reset Button: Whole machine will restart while press button
6. PoE Indicator: Yellow Light on: when device is powered
Light off: when device is not detected or not powered
7. Link/ Act Indicator: Green LED on: link up
Green LED off: link down
Green LED blinks: data transfer
8. Power indicator: Red Light on: with power; Light off: no power
Rear panel
1. Input: AC 96 264V~
2. Power Switch: Turn on with power, Turn off no power
3. Waiting Content
5. Ground Connection
6. Fuse: Max 10A
VLAN
OFF ON
