Metra. The World’s Best Kits.
®
MetraOnline.com © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 8/18/20 INST108-TO6HG
INSTALLATION INSTRUCTIONS
108-TO6HG
Patent Pending
Attention! Let the vehicle sit with the key
out of the ignition for a few minutes before
removing the factory radio. When testing the
aftermarket equipment, ensure that all factory
equipment is connected before cycling the
key to ignition.
KIT FEATURES
• ISO DDIN radio provision designed for 8” Pioneer modular radios†
• Painted gloss black
KIT COMPONENTS
• A) Radio trim panel • B) Radio brackets • C) #4 x 3/8” Phillips screws (4)
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
• 10mm Socket wrench • Cutting tool
TABLE OF CONTENTS
Dash Disassembly ..................................................2
Kit Assembly ..........................................................3
WIRING & ANTENNA CONNECTIONS
(sold separately)
Visit axxessinterfaces.com or metraonline.com
for harness and interface options
Antenna Adapter: 40-LX11
A B C
Toyota RAV4 2019-Up
Visit MetraOnline.com for more detailed information about the product and up-to-date vehicle
specific applications
† Refer to the radio manufacturer for current models
1.800.221.0932
|
MetraOnline.com
2
1. Remove the trim panel behind the radio.
(Figure A)
2. Remove (4) 10mm screws securing the
radio. Unclip and slide out the radio,
then unplug and remove. (Figure B)
3. Remove the (6) screws on radio back
and separate panels from around the
factory radio face. (Figure C)
Continue to Kit Preparation
(Figure B)
(Figure C)
(Figure A)
DASH DISASSEMBLY
