Metra. The World’s Best Kits.
®
MetraOnline.com © COPYRIGHT 2021 METRA ELECTRONICS CORPORATION REV. 7/9/21 INST95-7399B
INSTALLATION INSTRUCTIONS
95-7399B
Attention! With the key out of the ignition,
disconnect the negative battery terminal
before installing this product. Ensure that all
installation connections are secure before
cycling the ignition to test this product.
KIT FEATURES
• ISO DDIN radio provision
• Painted scratch resistant matte black
KIT COMPONENTS
• A) Radio trim panel • B) Radio brackets • C) Blank panel • D) Blank panel clip legs (2) • E) #6 x 3/8” Phillips screws (2)
• F) #8 x 1/4” Phillips screws (4) • G) Panel clips (2)
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
• Socket wrench
TABLE OF CONTENTS
Dash Disassembly ..................................................2
Kit Assembly ..........................................................3
A B C
E
F G
D
Hyundai Elantra 2019-2020
Visit MetraOnline.com for more detailed information about the product and up-to-date vehicle
specific applications
WIRING & ANTENNA CONNECTIONS
(sold separately)
Wiring Harness: 70-7304 (w/o 7-inch display radio)
• 70-7306 (with 7-inch display radio)
Antenna Adapter: N/A (w/o 7-inch display radio)
• 40-KI11 (with 7-inch display radio)
Please visit metraonline.com or axxessinterfaces.
com for other harness and interface options.
386.257.1187
|
MetraOnline.com
2
DASH DISASSEMBLY
1.
Open the passenger front door, then unclip
and remove the trim panel from the side
of dashboard. Remove the (1) Phillips
screw securing the silver trim panel
.
(Figure A)
2.
Unclip and remove the silver trim panel
that runs along the dashboard from
under the radio, and above the glovebox
.
(Figure B)
3. Open the driver’s door, then unclip and
remove the trim panel from the side of
the dashboard. Remove the (1) Phillips
screw securing the silver trim panel.
(Figure C)
4. Unclip and remove the silver trim panel
from under the driver’s side A/C vent.
(Figure D)
5. Unclip the trim panel above the steering
column, and then unclip and remove the
entire panel surrounding the instrument
cluster. Note, these two panels are one
assembly. (Figure E)
6. Remove the (2) Phillips screws securing
the radio trim panel, then unclip and
remove the panel. (Figure F)
7. Remove the (4) Phillips screws securing
the radio and then remove.
Continue to Kit Assembly
(Figure D)(Figure A)
(Figure E)(Figure B)
(Figure F)(Figure C)
