METRA. The World’s best kits.
™
metraonline.com
© COPYRIGHT 2004-2015 METRA ELECTRONICS CORPORATION
REV. 8/17/2015 INST99-8239B
Installation instructions for part 99-8239B
CAUTION!
Metra recommends disconnecting the negative bat
-
tery terminal before beginning any installation, unless the vehicle
manufacturer recommends against so. Please check with your local
Dealership for more information. All accessories, switches, climate
controls panels, and especially air bag indicator lights must be con
-
nected before reconnecting the battery or cycling the ignition. Also,
do not remove the factory radio with the key in the on position, or the
vehicle running. It would be best to remove the key from the ignition
and then wait a few seconds before removing the factory radio.
• ISO DIN radio provision with pocket
• Painted Matte Black
• A) Radio trim panel • B) Radio brackets • C) Pocket • D) (4) #8 x 3/8” Phillips pan head screws
• E) (2) #8 x 3/8 Phillips truss head screws
KIT FEATURES
KIT COMPONENTS
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness: • 70-1761
Antenna Adapter: • 40-LX11
• Panel removal tool • Phillips screwdriver • Socket wrench
TOOLS REQUIRED
Toyota Prius C 2012-2014
99-8239B
Dash Disassembly ................................................. 2
Kit Assembly
– ISO DIN radio provision with pocket ...................... 3
Table of Contents
A
B C D E
99-8239B
2
1. Unclip and remove the trim panel
from around the radio including the
hazard switch. (Figure A)
2. Remove (4) 8mm bolts securing
the factory radio, then unplug and
remove the radio. (Figure B)
Continue to kit assembly
Dash Disassembly
(Figure A)
(Figure B)
