METRA. The World’s best kits.
™
metraonline.com1-800-221-0932
© COPYRIGHT 2004-2014 METRA ELECTRONICS CORPORATION
REV. 12/9/2014 INST95-8215S
CAUTION: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
NOTE: Refer to the instructions included with the
aftermarket radio.
Installation instructions for part 95-8215S
• Double DIN radio provision
• Painted silver to match factory dash
• A) Radio trim panel • B) Brackets • C) (4) #8 x 3/8” Phillips screws • D) HVAC harness included (not shown)
KIT FEATURES
KIT COMPONENTS
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness: • HVAC harness included • TYTO-01 interface or 70-1761 harness
• ASWC-1 steering wheel control interface
Antenna Adapter: • Not required
• Panel removal tool • Phillips screwdriver
• Socket wrench
TOOLS REQUIRED
Toyota Avalon 2005-2010
95-8215S
A B C
Dash Disassembly
– Toyota Avalon 2005-2010 .................................... 2
Kit Assembly
– Double DIN radio provision ................................... 3
Table of Contents
95-8215S
2
Dash Disassembly
(Figure A) (Figure C)
(Figure B) (Figure D)
1. Unclip and remove small trim
piece from left side of panel above
steering wheel. (Figure A)
2. Unclip and remove panel above
steering wheel. (Figure B)
3. Unclip and remove entire panel
surrounding radio including A/C
controls. (Figure C)
4. Remove (4) 10 mm bolts securing
radio. (Figure D)
Continue to kit assembly
