Side 1/24

CAUTION!

All accessories, switches, climate

controls panels, and especially air bag indicator

lights must be connected before cycling the

ignition. Also, do not remove the factory radio

with the key in the on position, or while the

vehicle is running.

Metra. The World’s Best Kits.

INSTALLATION INSTRUCTIONS

99-3321B

KIT FEATURES

• ISO DIN radio provision with pocket

• ISO DDIN radio provision

• Painted matte black

KIT COMPONENTS

• A) Radio housing • B) Radio brackets • C) Pocket • D) (4) #8 x 3/8” Phillips screws

TOOLS REQUIRED

• Panel removal tool • Phillips screwdriver

• 7mm & 10mm socket wrench • Torx driver

• Allen wrench

TABLE OF CONTENTS

See inside front cover

WIRING & ANTENNA CONNECTIONS

(sold separately)

Wiring Harness: Please visit metraonline.com

for harness options

Antenna Adapter: Please visit metraonline.com

for antenna adapter options

A B C D

GM Multi-kit 2006-up*

*Visit MetraOnline.com for up-to-date vehicle speciﬁc applications.

APPLICATIONS

See inside front cover

1.800.221.0932

MetraOnline.com

APPLICATIONS TABLE OF CONTENTS

BUICK

Enclave 2008-2012

Lucerne 2006-2011

CHEVROLET

Avalanche 2007-2013

Captiva Sport 2012-2015

Equinox 2007-2009

Express 2008-up

Impala 2006-2013

Impala Limited (Fleet) 2014

Monte Carlo 2006-2007

Silverado ** 2007-2013

Silverado 2500/3500 2014

Suburban 2007-2014

Tahoe 2007-2014

Traverse 2009-2012

GMC

Acadia 2007-2012

Savana 2008-up

Sierra ** 2007-2013

Sierra 2500/3500 2014

Yukon 2007-2014

HUMMER

H2 2008-2009

PONTIAC

Torrent 2007-2009

SATURN

Outlook 2007-2010

Vue 2008-2010

SUZUKI

XL-7 2007-2009

Dash Disassembly

- Buick Enclave 2008-2012..........................................................................................................................................7

- Buick Lucerne 2006-2011..........................................................................................................................................3

- Chevrolet Avalanche 2007-2013 ..............................................................................................................................3

- Chevrolet Captiva Sport 2012-2015 ..........................................................................................................................8

- Chevrolet Equinox 2007-2009 ................................................................................................................................ 6

- Chevrolet Express 2008-up .....................................................................................................................................4

- Chevrolet Impala 2006-2013 ...................................................................................................................................3

- Chevrolet Limited (Fleet) 2014 ................................................................................................................................3

- Chevrolet Monte Carlo 2006-2007 ..........................................................................................................................3

- Chevrolet Silverado Pickup (excluding classic models) 2007-2013 ......................................................................3

- Chevrolet Silverado 2500/3500 2014 ......................................................................................................................3

- Chevrolet Suburban 2007-2014 ...............................................................................................................................3

- Chevrolet Tahoe 2007-2014 ......................................................................................................................................3

- Chevrolet Traverse 2009-2012 .................................................................................................................................7

- GMC Acadia 2007-2012 .............................................................................................................................................7

- GMC Savana 2008-up ...............................................................................................................................................4

- GMC Sierra (excluding classic models) 2007-2013 .................................................................................................3

- GMC Sierra 2500/3500 2014 .....................................................................................................................................3

- GMC Yukon 2007-2014 ..............................................................................................................................................3

- Hummer H2 2008-2009 ...........................................................................................................................................8

- Pontiac Torrent 2007-2009 ..................................................................................................................................... 6

- Saturn Outlook 2007-2010 .......................................................................................................................................7

- Saturn Vue 2008-2010 .............................................................................................................................................8

- Suzuki XL-7 2007-2009 .............................................................................................................................................5

Kit Assembly

- ISO DIN radio provision with pocket ...................................................................................................................... 9

- ISO DDIN radio provision ........................................................................................................................................10

** Excluding classic models
