REV. 1/25/2017 INST99-7631B
INSTALLATION INSTRUCTIONS FOR PART 99-7631B
METRA – The World’s best kits.
®
metraonline.com
© COPYRIGHT 2017 METRA ELECTRONICS CORPORATION
CAUTION!
All accessories, switches, climate controls panels,
and especially air bag indicator lights must be connected before
cycling the ignition. Also, do not remove the factory radio with
the key in the on position, or while the vehicle is running.
• ISO DIN radio provision with pocket
• Painted matte black
• A) Radio trim panel • B) Radio brackets • C) Pocket • D) (8) #8 x 3/8” Phillips screws
KIT FEATURES
KIT COMPONENTS
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness: • 70-7552 Antenna Adapter: • 40-NI12
• Panel removal tool • Phillips screwdriver
• 12mm socket wrench • T-20 Torx driver
TOOLS REQUIRED
Nissan Titan 2017-up, Titan XD 2016-up
99-7631B
Table of Contents
A B C D
Dash Disassembly ..............................................2-5
Kit Assembly .......................................................... 6
99-7631B
2
Dash Disassembly
1. Remove the (2) Phillips screws
securing the knee bolster panel
below the steering column, and
then unclip the panel. It is not
necessary to completely remove
the panel. (Figure A)
2. Unclip and remove the passenger
door sill and kick panel. (Figure B)
3. Remove the (5) T-20 Torx screws
securing the glove box and then
remove. There are (2) screws
below the glove box, and (3)
screws exposed when you open
the glove box. (Figures C and D)
Continued on next page
(Figure B)
(Figure D)
(Figure A)
(Figure C)
Upper screws
Lower screws
