Side 1/8
©COPYRIGHT 2021 METRA ELECTRONICS CORPORATION
Metraonline.comMetra Electronics Corp.
®
REV. 06/18/2021 INSTJP-JTKT
Attention!
When testing the aftermarket
equipment, ensure that all factory equip-
ment is connected before cycling the key to
ignition.
JP-JTKT
INSTALLATION INSTRUCTIONS
Camera Removal ................................................ 2-4
Assembly ................................................................ 5
Wiring .....................................................................6
Specifications ......................................................... 7
TABLE OF CONTENTS
TOOLS REQUIRED
• 5/32 Allen bit
• Torx T6H bit
• Zip-ties
Jeep Gladiator JT 2020-UP*
Replacement Camera Kit
*Visit Metraonline.com for more detailed informatuon about the product and up-to-date vehicle specific
applications.
A) Camera B) Bracket - 1 and 2 C) Harness
A B C
Product Features
• Designed to replace the LVDS camera on Jeep Gladiator
• Direct OE replacement
• ABS brackets
• Resolution: 550 TV lines
• Viewing Angle: 160 degrees
• Improved power circuit
386-257-1187
|
Metraonline.com
2
1. Remove the eight 5/32 bit screws from
the tailgate panel. (Figure A)
2. Remove the panel and safely set aside.
3. Remove the two 5/32 bit screws from the
smaller blue panel. (Figure B)
4. Remove the panel and safely set aside.
NOTE: Some trucks that do not have a bed
cover may look different. Make sure to safely
remove all screws and panels and set aside
before lifting up the tailgate.
Figure A Figure B
CAMERA REMOVAL
