Side 1/8
©COPYRIGHT 2021 METRA ELECTRONICS CORPORATION
iBEAMUSA.comiBEAM Vehicle Safety Sytems
®
REV. 04/18/2022 INSTTE-2PSK
Attention!
When testing the aftermarket
equipment, ensure that all factory equip-
ment is connected before cycling the key to
ignition.
TE-2PSK
INSTALLATION INSTRUCTIONS
#IBEAMSAFETY
Technical Tip............................................................2
Installation ......................................................... 3-5
Calibration ..............................................................6
Wiring digrams and specs ................................4-5
TABLE OF CONTENTS
TOOLS REQUIRED
• Wire stripper
• Tape
• Digital Multi-meter
• Cutter
• Alcohol wipes/cleaning pads
Universal 2 Sensor No Drill
Parking Sensor Kit
Visit iBEAMUSA.com for more detailed informatuon about the product and up-to-date vehicle specific
applications.
Product Features
• 2 sensor parking solution
• No need to drill into the bumper
• Audible 3-zone alerts
• No additional control box needed
• Use for plastic bumpers only
• Easy to install
Part Components
A) 2 Sensors B) Wiring harness C) Accessories
A B C
386-257-1187
|
iBEAMUSA.com
2
Installation
NOTE: This installation may require the
removing of the bumper to get the proper
sensor alignment.
1. Before removing of the bumper (if it
is needed) iBEAM suggests measuring
the placement of the sensors on
the outside of the bumper with the
provided ruler and painters tape.
2. Tape off the vertical mounting location
15-24 inches from the ground. Find the
flatest surface possible. (Figure A.1)
3. Find the center of the bumper. Tape
off two positions between 10 and 20
inches from the center on the left and
right hand side. Again, find the flatest
surface possible. (Figure A.2)
4. These tape markswill be used to
indicate where on the opposite side
the sensors will be mounted once the
bumper is removed.
5. Remove the bumper. Each vehicle is
different. Take care with removal, lay
a cloth on the ground to protect the
exterior paint from damage.
Figure A
15-24 in15-24 in 15-24 in
10-20 in10-20 in
1
2
2
TECHNICAL TIP
