24
/
7
T E C H N I C A L
S U P P O R T*
1-888-NETGEAR (638-4327)
Email: info@NETGEAR.com
NETGEAR ProSafe
®
Wireless LAN Antennas and Cables
ProSafe 14 dBi Patch Panel Directional Antenna - ANT24D18
ProSafe 10 dBi 2x2 Indoor/Outdoor Directional Antenna - ANT224D10
ProSafe 9 dBi Omni-directional Antenna - ANT2409
ProSafe 7 dBi Omni-directional Antenna - ANT2407
ProSafe 5 dBi 3x3 Omni-directional Antenna - ANT32405
ProSafe 5 dBi Omni-directional Antenna - ANT2405
ProSafe Low-Loss Antenna Cables
Data Sheet
Optimize WLAN Range and Power
NETGEAR’s ProSafe line of antennas and accessories for 802.11b, 802.11g and 802.11n
devices give you multiple options for maximizing the reach and performance of your wireless
infrastructure devices. Every WLAN deployment is unique. When planning a network
that incorporates wireless, varying facility sizes, construction materials, distance between
transmission points and physical obstructions must be accounted for. With both directional and
omni-directional antennas, indoor and outdoor options, low-loss cables, mounting hardware,
and other accessories, installers can customize a wireless solution that meets the requirements
of even the most challenging applications.
ProSafe 14 dBi Patch Panel
Directional Antenna
The ANT24D18 indoor/outdoor directional* 2.4 GHz antenna provides a 3-in-1 solution for
mixed applications in combination with an 802.11b or 802.11g access point or wireless router.
One, it delivers extended access point range in a single floor environment ideally positioned in
the corner of a building. Two, it functions point-to-point so that you can wirelessly connect LANs
between buildings in a campus-type environment. Three, it provides multifloor transmission
when placed on a ceiling, as the higher power output extends the range through typical flooring
materials. Includes several mounting options (fixed wall, wall adjustable, and pole),
cable sold separately.
*Directional: Concentrates transmit and receive radio-frequency energy into a cone, or beam, for higher signal
strength and reception in a single direction.
The ANT224D10 2.4 GHz antenna provides extended range connectivity for point-to-
point wireless bridges at wireless 802.11n speeds. With a maximum range of 8.5 KM, the
ANT224D10 enables high speed connections for building-to-building deployments. Additionally,
this antenna can be used indoors for floor-to-floor connectivity or to provide a narrow beam
of coverage. Due to the multiple streams of traffic in the 802.11n specification, this antenna
requires two antenna cables, which are available in a variety of lengths. It includes several
mounting options and comes with wall/pole mounting hardware. Cables are sold separately.
ProSafe 10 dBi 2x2
Indoor/Outdoor
Directional Antenna
ProSafe 9 dBi Indoor/Outdoor
Omni-directional Antenna
The ANT2409 indoor/outdoor 2.4 GHz antenna provides extended point-to-multi-point
coverage for wireless 802.11g devices. Optimal for medium range indoor or outdoor point-
to-multi-point applications. Included lightning arrestor (a $90 value) helps prevent damage
due to lightning-induced surges or static electricity in outdoor applications. Typically hung from
crossbars of drop ceilings or on a rooftop, the waterproof and UV resistant ANT2409 includes
wall and pole mounting materials for installation ease; antenna cable and grounding cable
not included.
ProSafe 7 dBi
Omni-directional Antenna
The ANT2407 indoor Omni-directional 2.4 GHz antenna enables improved coverage for
802.11g devices. Using passive RF shaping and enabling more optimal placement, the
ANT2407 can extend your range and improve your connectivity for 2.4 GHz devices. Integrated
magnets allow for mounting on magnetic surfaces such as file cabinets, white boards, and
ceiling T-bars. Desktop and wall mounting are also possible. With an integrated 1.5 m cable,
the ANT2407 can connect directly to an access point. Includes wall-mounting kit.
ProSafe 5 dBi 3x3
Omni-directional Antenna
The ANT32405 indoor 2.4 GHz antenna is for multiple-input-multiple-output wireless devices
such as 802.11n access points. Using three dipole antennas, the ANT32405 supports 3x3 or
2x3 streams of traffic, as supported by the 802.11n standard. Integrated magnetics enable
optimal placement of the antenna element, offering mounting capabilities on file cabinets,
white boards and ceiling T-bars. Desktop and wall mounting are also possible. With an
integrated 1m cable, the ANT32405 can connect directly to an access point. Includes
wall-mounting kit.
ProSafe 5 dBi
Omni-directional Antenna
The ANT2405 indoor omni-directional** antenna is designed to extend coverage of wireless
802.11b or 802.11g devices. This antenna is especially useful in optimizing coverage when you
want to place your wireless access point or router out of plain view – in a wiring closet or above
a ceiling pad. Locate this antenna at the top of a cubicle, on a ceiling, desktop or wall, where it
is more receptive to radio signals. Ideal placement is on a wall, 2 m high, or on the ceiling
facing the area to cover. Includes mounting brackets, cable sold separately.***
** Omni-directional: Radiates radio-frequency energy equally in all directions for widespread,
all-points deployment.
***NETGEAR recommends use of antenna cable up to 5 m long with the ANT2405 antenna.
NETGEAR ProSafe Wireless LAN Antennas and Accessories Antennas and Cables
NETGEAR ProSafe Wireless LAN Antennas and Accessories Antennas and Cables
ProSafe Wireless LAN Indoor/Outdoor Antennas
Product ANT24D18 ANT224D10 ANT2409
Description
ProSafe 14 dBi Patch Panel
Directional Antenna - ANT24D18
ProSafe 10 dBi 2x2 indoor/
outdoor directional antenna -
ANT224D10
ProSafe 9 dBi Omni-directional
Antenna - ANT2409
Wireless Signal IEEE 802.11g IEEE 802.11n IEEE 802.11g
Typical Application Indoor/Outdoor Indoor/Outdoor Indoor/Outdoor
Maximum Outdoor Range 21.4 km (13.3 miles)
1
8.5 km (5.28 miles)
4
11.5 km (7.2 miles)
2
Frequency Range 2400 - 2500 MHz 2400 - 2500 MHz 2400 – 2485 MHz
Gain 14 dBi
3
10 dBi
3
9 dBi
3
Beam Width
Horizontal 60°
Vertical 30°
Horizontal 33°
Vertical 32°
Horizontal 360°
Vertical 30°
Polarization Linear; Vertical Linear; Vertical Vertical
Operational Temperature -30° to 75° C (-22° to 167° F) -30º to 80º C (-22º to 176º F) -30º to 80º C (-22º to 176º F)
Dimensions
262 x 240 x 30 mm
(10.31 x 9.44 x 1.18 in)
240 x 240 x 40mm
(9.45 x 9.45 x 1.57 in)
625 x 75 x 56 mm
(24.6 x 2.95 x 2.2 in)
Weight 1.5 kg (3.35 lb) .7 kg (1.54 lb) .9 kg (2 lb)
Connectors
• Antenna - Reverse N female
• Lightening arrestor -
Reverse N female
• Adapter - Reverse SMA
• Antenna - N Jack Male
• Lightening arrestor - N Jack
Male to N Jack Male
• Extended Cable - N Plug
Female
• Antenna - Reverse N female
• Lightening arrestor - Reverse
N female
• Adapter - Reverse SMA
Package Contents
• 14 dBi Patch Panel Directional
Antenna ANT24D18 (cable
required, sold separately)
• Wall and pole mount brackets
and hanging materials
• One reverse N type to reverse
SMA adapter
• 2 m low-loss antenna cable
(to connect antenna to the
lightening arrestor)
• Lightening arrestor
• Installation guide and
Warranty/support card
• NETGEAR ProSafe Indoor/
Outdoor 10 dB 2x2 Directional
Antenna ANT224D10
• 2 lightning arrestors with
30 cm low-loss cables
• 2 reverse N/SMA adapters
• Wall mount and pole
mounting hardware
• Installation Guide and
Warranty/ Support card
• Indoor/Outdoor 9 dBi
Omni-directional
• Antenna - ANT2409 (cable
required, sold separately)
• Wall and pole mount brackets
and hanging materials
• One reverse N type to reverse
SMA adapter
• 2 m low-loss antenna cable
(connection for lightening
arrestor)
• Lightening arrestor
• Installation guide and
Warranty/support card
Warranty NETGEAR 2-year warranty NETGEAR 2-year warranty NETGEAR 2-year warranty
Ordering Information
(all regions)
ANT24D18 ANT224D10-10000S ANT2409-20000S
Produkspesifikasjoner
| Merke: | Netgear |
| Kategori: | Wifi-antenne |
| Modell: | ANT24D18 |
| Vekt: | 1520 g |
| Bredde: | 262.8 mm |
| Dybde: | 262.8 mm |
| Høyde: | 40 mm |
| Antenne forbedringsnivå (max): | 18 dBi |
