Side 1/2
ProSafe 16-Port Ethernet Switch with
8-Port PoE FS116P
Step 2. Connect power Step 3. Check status
Optional
modem
Step 1. Connect equipment
FS116P
Optional router
Computer Server
Internet
Installation Guide
On
Off
Power LED
Activity (blinking)
No link (off)
(right LED)
10 Mbps link
Port 9-16 LEDs
(left LED)
100 Mbps link
Less than 7W of
PoE power is available
PoE Max. LED
PoE ports are
working normally (off)
PoE MAX LED was
active in the previous
2 minutes
PoE in use
No PoE use (off)
Activity (blinking)
No link (off)
10 Mbps link
Port 1-8 right LEDs
100 Mbps link
PoE fault
Port 1-8 left LEDs
FS116P IG 21sept12.fm Page 1 Friday, September 21, 2012 11:17 AM
September 2012
This symbol appears in accordance with the European Union Directive 2002/96 on the Waste
Electrical and Electronic Equipment (the WEEE directive). If you dispose of this product in the
European Union, treat and recycle it in accordance with your jurisdiction’s laws that implement the
WEEE directive.
NETGEAR, the NETGEAR logo, and Connect with Innovation are trademarks and/or registered trademarks of
NETGEAR, Inc. and/or its subsidiaries in the United States and/or other countries. Information is subject to
change without notice. Other brand and product names are registered trademarks or trademarks of their
respective holders. © NETGEAR, Inc. All rights reserved.
For indoor use only in all EU countries and Switzerland.
For the complete EU Declaration of Conformity, visit
http://support.netgear.com/app/answers/detail/a_id/11621/.
Statement of Conditions: In the interest of improving internal design, operational function, and/or reliability,
NETGEAR reserves the right to make changes to the products described in this document without notice.
NETGEAR does not assume any liability that may occur due to the use or application of the product(s) or circuit
layout(s) described herein.
Specifications
Specification Description
Network interface RJ-45 connector for 10BASE-T, or 100BASE-TX
Network cable Category 5 (Cat 5) or better Ethernet cable
Ports 16
Power adapter 48V @ 1.45A DC input
Power consumption 70W max.
PoE Power budget 55W max. (all PoE ports, Port 1 – Port 8), 15.4W max. per PoE
port
Weight 0.7 kg (1.56 lbs)
Dimensions
(W x D x H)
287 mm x 103 mm x 27 mm
11.3 in. x 4.1 in. x 1.1 in.
Operating
temperature
0° to 40° C (32° to 104° F)
Operating humidity 10% to 90% relative humidity, non-condensing
Electromagnetic
compliance
CE Class A, FCC Class A, VCCI Class A,
Safety agency
approvals
CB, CCC
Technical Support
After installing your device, locate the serial number on the label of your product and
use it to register your product at .https://my.netgear.com
You must register your product before you can use NETGEAR telephone support.
NETGEAR recommends registering your product through the NETGEAR web site.
For product updates and web support, visit .http://support.netgear.com
FS116P IG 21sept12.fm Page 2 Friday, September 21, 2012 11:17 AM
