For Technical Support: www.panduit.com/resources/install_maintain.asp

INSTALLATION INSTRUCTIONS

FS119A

LC Fiber Optic Connectors

Field Polish Termination - Singlemode and Multimode

ITEM PART NUMBER DE CRIPTIONS

1 CST-115 Fiber C ble Ja acket tripperS

2 FALC Alcohol Bottle (empty)

3 S u SFBF P Fiber B ffer tripper

4 FLPT LC Crimp Tool

5 FS a SCRIBE C rbide cribe

6 FGLS Safety Gl eass s

7 FLCPK LC Poli hing P ck (1.25mm Ferr le)s u u

8FJPMR Primer

9 a sFJPXY An erobic Adhe ive

FH CT (or)S

FH CT-WS

He t hrink C ring Tool (110VAC / 60Hz for 1.6mm/2.0mm in t ll tion)a S u s a a

He t hrink C ring Tool (2 0VAC / 50Hz for 1.6mm/2.0mm in t ll tion)a S u 3 s a a

11 FK ArS amid Yarn S a she r

12 FPP5-L 5µm Poli hing Film (Als u

min m Oxide)u

1 FPF1-V 1µm Di mond Poli hing Film3 a s

14 FLCPAD 5 D rometer Poli hing P8 u s ad

15 F CDVR crewdriverS S

16 F COPE 200x Micro copeS s

17 FLCA CP 1.25mm Ad pter for F COPES a S

1 F TY fety for fiber cr8 S Sa Stickers s a sp

1 F WB-C Cle ning w b9 S a S a s

20 F YR-X yringe with needle tipS S s s

21 FTWZR Tweezers

22 FWP-C Cloth Wipes

2 PFX-0 Indelible Ink M rking Pen3 a

24 FLOUPEX10 Eye Lo pe 10X Poweru

25 -- I opropyl Alcohol (Re gent Grs a a 9 ude, 0% minim m concentration; not av ila

able from Pa und it)

26 FLCFPLF-X .05µm L pping Film (For inglemode termin tion only) a s a s

27 FWBTL Distilled Water Bottle (empty)

-- -- Distilled Wa ater (not va ail ble from Pa und it)

OPTIONAL PN 5* LC Connector 33 Stripping Template

DUPLEX

Duplex Clip

CONNECTOR ASSEMBLY

ITEMS REQUIRED FOR TERMINATION

SIMPLEX

Dust cap

Connector Body

Backbone

Crimp Sleeve

900µm Boot

Jacketed Boot

with heat shrink

tubing

READ ALL INSTRUCTIONS COMPLETELY BEFORE PROCEEDING

Page 1 of 11

COMPONENT IDENTIFICATION

* denotes stripping template revision letter.
