Industrial 5-/8-Port 10/100TX

Compact Ethernet Switch

ISW-500T/ISW-800T

User's Manual

Table of Contents

1. Package Contents ..........................................................................................3

2.ProductSpecications ....................................................................................4

3. Hardware Introduction ...................................................................................6

3.1 Three-View Diagram ................................................................................6

3.2 Front View .............................................................................................8

 3.3 LEDDenition ........................................................................................ 8

3.4 Top View ................................................................................................ 9

3.5 Wiring the Power Inputs .......................................................................... 9

3.6 Wiring the Fault Alarm Contact .............................................................. 12

3.7 Grounding the Device ............................................................................ 12

4. Installation .................................................................................................. 13

4.1 DIN-rail Mounting Installation................................................................. 13

4.2 Wall-mount Plate Mounting .................................................................... 14

4.3 Side Wall-mount Plate Mounting ............................................................. 14

5. Customer Support ....................................................................................... 15

1. Package Contents

Thank you for purchasing PLANET industrial 5-/8-port 10/100TX Compact Ethernet

Switch, ISW-500T/800T. In the following section, the term “Industrial Ethernet

Switch” means the ISW-500T or ISW-800T.

Open the box of the Industrial Ethernet Switch and carefully unpack it. The box

should contain the following items:

Industrial Ethernet Switch x 1 QR Code Sheet x 1

Let’s get started with your PLANET product

ISW-500T

Please scan the QR code to browse our online User’s Manual or Quick

Installation Guide and follow the instructions to complete the setup.

User's Manual

Bitte scannen Sie den QR Code sie werden per Browser zur

Bedienungsanleitung oder Schnellanleitung weiter geleitet. Folgen Sie den

Anweisungen um die Installation abzuschließen.

Veuillez scanner le code QR pour obtenir notre Notice d’Utilisation en

ligne ou notre Guide d’Installation Rapide et suivez les instructions pour

compléter la conguration

Escanee el código QR para encontrar el Manual del Usuario en línea o

la Guía de Instalación Rápida y siga las instrucciones para completar la

conguración.

Scansiona il codice QR per consultare online il Manuale utente o la Guida di

installazione rapida e segui le istruzioni per completare la congurazione.

Por favor, escaneie o QR code para navegar no Manual do Usuário ou Guia

de Instalação Rápida. Siga as instruções para completar a conguração.

Zeskanuj kod QR, aby otworzyć naszą internetową instrukcję obsługi

lub instrukcję szybkiej instalacji. Postępuj zgodnie z instrukcjami, aby

zakończyć poprawną kongurację.

One word modify: Отсканируйте QR-код, чтобы просмотреть наше

онлайн-руководство пользователя или руководство по быстрой

настройке, и следуйте инструкциям для завершения настройки

Te rugam sa scanezi codul QR, pentru a descarca User’s Manual sau Quick

Installation Guide si a urmari instructiunile necesare in nalizarea instalarii

Need more help?

PLANET online FAQs:

http://www.planet.com.tw/en/support/faq

Technical Support: support@planet.com.tw

Contents are subject to revision without prior notice.

PLANET is a registered trademark of PLANET Technology Corp.

All other trademarks belong to their respective owners.

Part No. 2360-AH0780-001

DIN-rail Kit x 1 Wall-mount Kit x 1 RJ45 Dust Cap

ISW-500T x 5

ISW-800T x 8

If any of these are missing or damaged, please contact your dealer immediately;

if possible, retain the carton including the original packing material, and use them

again to repack the product in case there is a need to return it to us for repair.
