PureLink PT-MA-HD88DA Bruksanvisning

PureLink Bryter PT-MA-HD88DA

Les nedenfor 📖 manual på norsk for PureLink PT-MA-HD88DA (52 sider) i kategorien Bryter. Denne guiden var nyttig for 2 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/52

User Manual

PT-MA-HD88DA

User Manual

8x8 HDMI 2.0 Matrix 4K (60Hz 4:4:4) HDR with Downscaling

Model PT-MA-HD88DA

Designed in Germany

User Manual

PT-MA-HD88DA

Preface

Read this user manual carefully before using this product. Pictures shown in this manual

are for reference only. Different model layouts and specifications are subject to the

physical product.

This manual is for operation instructions only, not for any maintenance usage.

In the constant effort to improve our product, we reserve the right to make changes in

functions or parameters without prior notice or obligation.

Trademarks

Product model and logo are trademarks. Any other trademarks mentioned in this manual

are acknowledged as the properties of the trademark owner. No part of this publication

may be copied or reproduced without the prior written consent.

FCC Statement

This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference to

radio communications. It has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a commercial installation.

Operation of this equipment in a residential area is likely to cause interference, in which

case the user at their own expense will be required to take whatever measures may be

necessary to correct the interference.

Any changes or modifications not expressly approved by the manufacture would void the

user’s authority to operate the equipment.

User Manual

PT-MA-HD88DA

REACH | 1907/2006/EU

ROHS | 2011/65/EU

PureLink hereby declares that this product PureTools PT-MA-HD88DA complies with

Directives 1907/2006/EU und 2011/65/EU.

EMC / LVD (Electro Magnetic Compatibility / Low Voltage Directive)

PureLink GmbH hereby declares that this product PureTools PT-MA-HD88DA complies

with Directives 2014/30/EU and 2014/35/EU. The full text of the EU Declaration of

Conformity is available at the following Internet address:

http://www.purelink.de/ce/4251364722015_CE.pdf

Produkspesifikasjoner

Merke:	PureLink
Kategori:	Bryter
Modell:	PT-MA-HD88DA
Produkttype:	Skalerende matrisevelger
Innebygd skjerm:	Nei
Vekt:	3000 g
Bredde:	436.4 mm
Dybde:	236 mm
Høyde:	44 mm
LED-indikatorer:	Link, Operation, Power
Bruksanvisning:	Ja
USB-kontakttype:	USB Type-A
Maksimal oppløsning:	3840 x 2160 piksler
HDMI-versjon:	2.0
Antall HDMI-inngangsporter:	8
Utgangsstrøm:	24 V
HDCP-versjon:	2.3
Antall skruer:	6
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 / 60 Hz
Fiberoptisk kontakt:	Toslink
Antall USB-porter:	1
RS-232-port:	1
Lydinngang (V/H) inn:	8
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	-5 - 55 °C
Oppbevaringstemperaturomåde (Celsius):	-25 - 70 °C
Fjernkontroll medfølger:	Ja
Harmonisert system (HS)-kode:	85299097
Skruer inkludert:	Ja
DC-inngangskontakt:	Ja
Av/på-bryter:	Ja
Relativ luftfuktighet under drift (H-H):	10 - 90
Antall HDMI-utgangsporter:	8
Lydutgang (venstre/høyre):	8
AC-adapter bunt:	Ja
HDR (High Dynamic Range) støttes:	Ja
Største båndbredde for port:	18 Gbit/s
Digital optisk lydinngang:	4
Optisk digital lydutgang:	4
IR-mottaker inkludert:	Ja
Lyd-kanaler:	2
