MDU- 40
Item ref: 173.637UK
Mini Desktop U Microphone SB
User Manual
Setting up
The MDU- is a miniature desktop microph with back-electret capsule40 one ,
designed to provide a more direct and higher quality input for voice
recording or streaming via a ptop or desktop computer. la
The MDU-40 has a cylindrical metal body and dome grille and is supplied
with a custom desktop stand that fixes to the bottom of the microphone
body The M -40 has a USB type-C socket at the rear and is supplied with . DU
a type-C to type-A lead for connection to USB port on a Mac or Windows a
computer. This provid power to the microphone and delivers the s es ound
picked up by the capsule a digital audio signal to the computer. as
The computer will recognise the MDU- USB PnP Sound Device40 as a “ ” in
the sound or audio settings.
Operation
Selecting the MDU- (40 “USB PnP Sound Device as the input device within the recording or streaming ”)
software will set the microphone as the input source. An illuminated button on the top of the body will
mute the microphone as required.
The MDU- can be disconnected and re-connected to USB as a hot-swappable device. 40
Disconnect from USB after use to preserve the computer battery or power supply.
Specifications
Power supply
5Vdc (from USB)
Capsule
9.7mmØ back electret condenser
Polar pattern
Cardioid
Frequency response
20Hz - 20kHz
Sensitivity
-52dB
S/N ratio
78dB
Max. input sound level
110dB
USB cable length
1.5m (type C to A)
USB version
v2.0
Dimensions
140 x 94 x 58mm
Weight
197g
Disposal: The “Crossed Wheelie Bin” symbol on the product means that the product is classed as
Electrical or Electronic equipment and should not be disposed with other household or commercial waste
at the end of its useful life. The goods must be disposed of according to your local council guidelines.
Errors and omissions excepted. Copyright© 2022. AVSL Group Ltd.
Unit 2-4 Bridgewater Park, Taylor Rd. Manchester. M41 7JQ
AVSL (EUROPE) Ltd, Unit 3D North Point House, North Point Business Park, New Mallow Road, Cork, Ireland
Produkspesifikasjoner
| Merke: | QTX |
| Kategori: | Mikrofon |
| Modell: | MDU-40 |
