Salicru SPS 16 ATS Bruksanvisning

Salicru Bryter SPS 16 ATS

Les nedenfor 📖 manual på norsk for Salicru SPS 16 ATS (16 sider) i kategorien Bryter. Denne guiden var nyttig for 4 personer og ble vurdert med 4.5 stjerner i gjennomsnitt av 2 brukere

Last ned PDF

Side 1/16

SPS ATS

AUTOMATIC TRANSFER SYSTEM

USER MANUAL

2 SALICRU

General index.

1. INTRODUCTION.

1.1. THANK YOU LETTER.

2. SAFETY INFORMATION.

2.1. USING THIS MANUAL.

2.1.1. Conventions and symbols used.

3. QUALITY ASSURANCE AND STANDARDS.

3.1. STATEMENT BY THE MANAGEMENT.

3.2. STANDARDS.

3.2.1. First and second environment.

3.2.1.1. First environment.

3.2.1.2. Second environment.

3.3. ENVIRONMENT.

4. PRESENTATION.

4.1. VIEWS.

4.1.1. Views of the device.

4.1.2. Key to the views of the SPS.

4.2. NOMENCLATURE.

4.3. OPERATING PRINCIPLE.

4.3.1. Block diagram.

5. INSTALLATION.

5.1. RECEPTION OF THE DEVICE.

5.1.1. Reception, unpacking and contents.

5.1.2. Storage.

5.2. SITING IN A 19” RACK CABINET.

5.2.2.1. Preliminary considerations before connection and siting

requirements.

5.3. CONNECTIONS.

5.3.1. Connection of the input for SPS 16 ATS models.

5.3.2. Connection of the input for SPS 32 ATS models.

5.3.3. Connection of the loads to the output connectors.

5.3.4. Communication port.

5.3.4.1. RS232, USB and interface to relays port.

5.3.5. Smart slot for the integration of an electronic communication

unit, S NMP.

5.3.6. Management and monitoring software.

6. OPERATION.

6.1. S TA R T UP.

6.2. FORCED MANUAL TRANSFER OF INPUT.

6.3. READING THE PARAMETERS.

6.4. AUDIBLE ALARM.

6.5. INFORMATION REPRESENTED BY THE DISPLAY.

6.6. LED INDICATIONS.

7. MAINTENANCE, WARRANTY AND SERVICE.

7.1. UPS TROUBLESHOOTING GUIDE.

7.2. WARRANTY CONDITIONS.

7.2.1. Terms of the warranty.

7.2.2. Exclusions.

7.3. TECHNICAL SERVICES NETWORK.

8. ANNEXES.

8.1. GENERAL TECHNICAL SPECIFICATIONS.

SPS ATS AUTOMATIC TRANSFER SYSTEMUSER MANUAL

Produkspesifikasjoner

Merke:	Salicru
Kategori:	Bryter
Modell:	SPS 16 ATS
Vekt:	4000 g
Bredde:	438 mm
Dybde:	275 mm
Høyde:	44 mm
LED-indikatorer:	Ja
USB-port:	Ja
Sertifisering:	EN-55022; EN-55024, ISO 9001 & ISO 14001
Utgangsstrøm:	16 A
Sikkerhet:	IEC-60950-1
Utgangsspenning (maks.):	240 V
Effektivitet:	99
AC-inngangsfrekvens:	50 - 60 Hz
Inngangsspenning (maks.):	300 V
SmartSlot:	Ja
Produktfarge:	Black, Grey
RS-232-port:	2
Driftstemperatur (T-T):	0 - 40 °C
Formfaktor:	Rackmontering
Rack-kapasitet:	1U
Relativ luftfuktighet under drift (H-H):	0 - 95
Display:	LCD
Antall AC outlets:	9 AC-utganger
AC-utgangstyper:	C13 coupler, C19 coupler
Inngangsspenning (min.):	150 V
Utgangsspenning (min.):	200 V
AC-inngangstype:	2 x C20-koblinger
