Side 1/110
Air Conditioner
Installation manual
AM***FXVAF* / AM***FXVAJ* / AM***HXVAF* / AM***HXVAJ* /
AM***KXVTF* / AM***KXVTJ* / AM***KXVGJ*
• Thank you for purchasing this Samsung Product.
• Before operating this unit, please read this installation manual carefully and retain it for future
reference.
2
Contents
Safety precautions ....................................................................................................... 3
Preparing for installation ................................................................................................. 6
Selecting installation location ........................................................................................... 11
Space requirement for installation ...................................................................................... 13
Accessories ............................................................................................................. 15
Base construction and installation of the outdoor unit ................................................................... 17
Installing the wind/snow prevention duct ............................................................................... 22
Refrigerant pipe installation ............................................................................................. 24
Electrical wiring work ................................................................................................... 59
Air tightness test and vacuum drying ................................................................................... 75
Pipe insulation .......................................................................................................... 77
Charging additional refrigerant ......................................................................................... 81
Basic segment display .................................................................................................. 83
Setting outdoor unit option switch and key function .................................................................... 83
Setting the MCU and Pipe Addresses (for HR Only) ...................................................................... 93
Things to check after completing the installation ........................................................................ 97
Inspection and trial operation ........................................................................................... 99
Automatic refrigerant amount detection function ...................................................................... 105
3
ENGLISH
Safety precautions
California Proposition 65 Warning (US)
WARNING:
Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
Please follow the following safety information for safety of the installer and the user.
❋ DVM S air conditioner uses R-410A refrigerant.
• When using R-410A, moisture or foreign substances may aect the performance and reliability of the product.
Safety precautions must be obeyed when installing the refrigerant pipe.
• The designed maximum pressure of the system is 4.1MPa(594.6 psi) and therefore select appropriate material and
thickness according to the regulations.
• R-410A is a quasi-azeotrope of two refrigerants and it has to be charged in liquid phase when lling the refrigerant.
(If you charge vapor refrigerant, it may change the blend of the refrigerant and cause product malfunction.)
❋ You must connect the indoor units for R-410A refrigerant. Refer to product catalog to nd out the models names
for connectable indoor units. (If you connect the indoor units that are not designed for R-410A, it cannot operated
normally.)
❋ After completing the installation and trial operation, explain to the user how to use and maintain the product. Also, hand
over this installation manual so that it can be stored by the user.
❋ Manufacturer is not responsible for the incidents occurred by improper installation. Installer is responsible for any
installation related claims from the user occurred by neglecting warnings and cautions stated in this manual. (Installer
will be responsible for any service charges that may occur)
❋ Generally, system air conditioners should not be relocated after installation. But when it has to be relocated for inevitable
reasons, please contact Samsung’s qualied dealers for system air conditioners.
WARNING
• Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
• Hazards or unsafe practices that may result in minor personal injury (to installer/user) or
property damage.
SEVERE WARNING SIGNS
Consult qualied installer or dealer for installation.
f When installation is done by unqualied person, problems such as water leakage, electric shock or re may occur.
Installation work must be done properly according to this installation manual.
f When installation is not done properly, it may cause water leakage, electric shock or re.
When installing the unit in a small room, take measure to keep the refrigerant concentration from exceeding allowable
safety limits in case of refrigerant leakage. Consult the dealer for precautionary measure before the installation.
f When refrigerant leaks and exceed dangerous concentration level, it may cause suocation accidents.
If any gas or impurities, except R-410A refrigerant, come into the refrigerant pipe, serious problem may occur and it
may cause injury.
Use the supplied accessories, specied components and tools for the installation.
f Do not use the pipe and the installation product used for the R-22 refrigerant.
f Failure to use the specied components can cause product fall down, water leakage, electrical shock, and re. (The pipe
and are components used for R-22 refrigerant must not be used)
Install the outdoor unit on a hard and even place that can support its weight.
f If the place cannot support its weight, the outdoor unit may fall down and it may cause injury.
