Side 1/6

Model No.

Material

Pin definition

Included Parts

Watt

Tandem limits

Length

Weight

Displays any color by use of a RGB LED control box or capable motherboard

Coating with special light diffusion material improves light uniformity

Built-in magnetic strip and adhesive tape provides more installation freedom

Supports daisy chaining multiple light strips

LED strip is a must have for any enthusiast looking to brighten up their PCs. Improving upon

SilverStone’s first light strip product, the LS01, the LS02 has three more LEDs for a total of

18 for extra brightness. By injecting the clear coating with special light diffusion material, it

disperses its colors smoother and with better uniformity. LS02 can be controlled by hardware

or software that can manipulate +12V, G, R, B, signals such as RGB LED control box or

motherboard to display user’s desired colors. It also has the ability to daisy chain multiple

light strips to accommodate various applications. Finally, to improve ease of installation and

replacement, the LS02 has both built-in magnetic strip and adhesive tape to better meet the

demand of enthusiasts that require more flexibility in installation.

* Please check the control box and motherboard pin header that you want to connect are the same as LS02’s pin definition.

** Included Y cables support SilverStone’s RGB 4pin connectors and other market standard RGB 4pin connectors.

SST-LS02

18 pcs 5050 RGB LED with magnetic strip and adhesive tape

+12V, G, R, B*

RGB LED strip x 2

Y cable x 2**

1.44W (12V, 0.12A)

5 pcs on each line

300mm

30g

Specifications

Special Features

Introduction

Для установки LS02 в корпус или на другие

поверхности используйте магнитную или клейкую

полосы на задней стороне светодиодной ленты

利用背面磁條或是背膠將燈條固定於所欲

安裝的位置

利用背面磁条或是背胶将灯条固定于所欲

安装的位置

Use the magnetic stripe on the back or the

adhesive strip to affix LS02 to the location you

wish to install

Use the magnetic stripe on the back or the

adhesive strip to affix LS02 to the location you

wish to install

Befestigen Sie den LS02 mit dem rückseitigen

Magnetstreifen oder dem Klebeband an der

gewünschten Position

Use la cinta magnética en la parte posterior ó la

cinta adhesiva para fijar la LS02 al lugar donde

desee instalarla

Utilizzare la striscia magnetica sul retro o la

striscia adesiva per fissare LS02 sul punto di

installazione

Installation

背面のマグネットストリップまたは粘着テー

プを使用して、LS02インストールしたい箇所

へ固定します

뒷면의 자석 스트립이나 접착 테이프를

사용하여 LS02를 설치하려는 위치에

부착하십시오

Используйте входящий в комплект кабель-

удлинитель для подключения LS02 к материнской

плате, блоку управления или другим

совместимым устройствам

使用內附的延長線連接燈條與主機板或是

控制盒等訊號源裝置

使用内附的延长线连接灯条与主板或是

控制盒等讯号源装置

Use the included extension cable to connect

LS02 to motherboard, control box, or other

compatible devices

Verbinden Sie den LS02 über das mitgelieferte

Verlängerungskabel mit Motherboard,

Steuerbox oder anderen kompatiblen

Geräten

Utilisez le câble d'extension inclus pour

raccorder le LS02 à une carte mère, un boîtier

de commande ou d'autres appareils

compatibles

Use el cable de extensión incluido para

conectar la LS02 a la placa base, caja de

control u otro dispositivo compatible

Utilizzare la prolunga in dotazione per collegare

LS02 a scheda madre, box di controllo o altri

dispositivi compatibili

LS02をマザーボード、コントロールボックス、

またはその他互換デバイスに接続する際は、

付属の延長ケーブルをご使用ください

포함된 연장 케이블을 사용하여 LS02를

마더보드, 컨트롤 박스 또는 기타 호환되는

장치에 연결하십시오

Produkspesifikasjoner

Merke:	SilverStone
Kategori:	Datamaskinbehuizing
Modell:	LS02
Vekt:	30 g
Bredde:	300 mm
Strømforbruk (maks.):	1.44 W
Sertifisering:	ASUS Aura Sync, MSI Mystic Light Sync
Antall per pakke:	2 stykker
Inngangsspenning:	12 V
Utgangsstrøm:	0.12 A
Produktfarge:	Black, White
lys farge:	Blue, Green, Orange, Red, White, Yellow
Modell/Type:	LED-stripe
Magnetfeste:	Ja
