Side 1/8

SDP10

5.25” to 3.5” and 2.5” bay converter

Support one 3.5” HDD and two 2.5” HDD/SSD

Compatible with most computer cases

Special Features

Introduction

Hard drive installation

The SDP10 is a new generation of 5.25” to 3.5” drive bay bracket that is

capable of accommodating two additional 2.5” hard drives or SSDs

(9.5mm thickness) in addition to a 3.5” drive. If you are building a system

in which additional hard drive space is required and there are free 5.25”

drive bays, the SDP10 is a great choice.

Install the 3.5” hard drive and secure with included #6-32 screws

Installieren Sie die 3,5 Zoll-Festplatte, anschließend mit den beigelegten

#6-32-Schrauben fixieren.

Installez le disque dur 3.5” et fixez-le avec les vis #6-32 fournies

Instale el disco duro de 3,5” y fíjelo con los tornillos #6-32 incluidos.

Utilizzare quindi le viti #6-32 per il montaggio delle hard disk da 3,5”

3.5" 하드 드라이브를 설치하고 제공된 #6-32 나사를 사용하여 고정합니다.

3.5”ハードディスクドライブを取り付け、付属の#6-32ネジで固定します。

安裝3.5”硬碟，以內附的#6-32螺絲鎖固。

将卡榫扳开，取下拉带，将硬盘抽出。

Установите 3.5-дюймовый жесткий диск и закрепите прилагаемыми

болтами #6-32

Specification

Install the 2.5” hard drive and secure with included M3 screws

Installieren Sie die 2,5 Zoll-Festplatte, anschließend mit den beigelegten

M3-Schrauben fixieren.

Installez le disque dur 2.5” et fixez-le avec les vis M3 fournies

Instale el disco duro de 2,5” y fíjelo con los tornillos M3 incluidos.

Utilizzare quindi le viti M3 per il montaggio delle hard disk da 2,5”

Adjust SDP10’s position to ensure that it does not interfere with the drive

bay cover and secure it with screws. If the case does not have any

more mounting holes for adjustment, the SDP10 has additional set of

holes to allow for moving it further into the case.

Passen Sie die Position des SDP10 so an, dass es nicht

mit der Schachtabdeckung kollidiert; anschließend mit Schrauben

fixieren. Falls die Montagebohrungen nicht zur Anpassung ausreichen

sollten, verfügt das SDP10 über zusätzliche Bohrungen, damit es nahezu

frei platziert werden kann.

2.5" 하드 드라이브를 설치하고 제공된 M3 나사를 사용하여 고정합니다.

A. Internal 3.5” device installation with common 5.25” drive bay cover

2.5” ハードディスクドライブを取り付け、付属のM3ネジで固定します。

安裝2.5”硬碟,並以內附的沉頭M3螺絲鎖固。

安装2.5”硬盘,并以内附的沉头M3螺丝锁固。

Установите 2.5-дюймовый жесткий диск и закрепите прилагаемыми болтами M3

Install the SDP10 into the chassis

Produkspesifikasjoner

Merke:	SilverStone
Kategori:	Datamaskinbehuizing
Modell:	SDP10
Vekt:	280 g
Bredde:	148 mm
Dybde:	152.8 mm
Høyde:	41.3 mm
Materiale:	Stål
Antall per pakke:	1 stykker
Størrelse:	5.25 "
Produktfarge:	Sort
Modell/Type:	HDD-bur
